CARBURETOR

RM250 1982 (Z) USA (E03)

Carburetor diagram RM250 1982 (Z) USA (E03)

CARBURETOR RM250 1982 (Z) USA (E03)
CARBURETOR RM250 1982 (Z) USA (E03)
CARBURETOR RM250 1982 (Z) USA (E03)
prices are in EUR
ref
part #
description
quantity
0-1
1320014300
ref: 0-1
CARBURETOR ASSEMBLY
€ 0.00
0-2
1320014310
ref: 0-2
CARBURETOR ASSEMBLY (VM38)
€ 0.00
1
1325114300
ref: 1
GASKET,FLOAT CAHMBER (NAS)
1325114300
€ 10.50
2
1339410010
ref: 2
CLIP
1339410010
€ 4.50
3
0949255005
ref: 3
JET,PILOT
€ 6.50
4
1325340010
ref: 4
ARM,FLOAT
1325340010
€ 8.00
5
0211204128
ref: 5
02112-0412A
SCREW
0211204128
€ 1.50
6
0832121048
ref: 6
08321-0104A
LOCK WASHER
0832121048
€ 2.00
7
1325492311
ref: 7
PIN,FLOAT
1325492311
€ 2.00
8
1337014300
ref: 8
13370-43B00
VALVE ASSEMBLY,NEEDLE
€ 52.50
9-1
0949400356
ref: 9-1
JET,NEEDLE
0949400356
€ 17.00
9-2
0949400393
ref: 9-2
JET,NEEDLE
0949400393
€ 20.00
10
1338314300
ref: 10
NEEDLE,JET
1338314300
€ 12.50
11
1333114300
ref: 11
RING,MAIN JET FIXING
€ 0.00
12-1
0949158001
ref: 12-1
09491-58002
JET
€ 7.50
12-2
0949160007
ref: 12-2
JET,MAIN(300)
0949160007
€ 9.50
13
1324732210
ref: 13
SCREW,GUIDE
1324732210
€ 13.00
14
1324941310
ref: 14
O RING,DRAIN PLUG
1324941310
€ 5.00
15
1325218620
ref: 15
FLOAT
1325218620
€ 27.50
16
0211205208
ref: 16
02112-05207
SCREW 5X20
0211205208
€ 3.00
17
0832121058
ref: 17
08321-0105A
LOCK WASHER
0832121058
€ 2.00
18
1326946010
ref: 18
13269-95110
SCREW,PILOT AIR
1326946010
€ 8.50
19
1326801010
ref: 19
SPRING
1326801010
€ 3.50
20
1337339110
ref: 20
PLATE
1337339110
€ 6.50
21
0211204068
ref: 21
02112-0406B
SCREW 4X6
0211204068
€ 2.00
22
1368133010
ref: 22
CAP,CABLE ADJUSTER
1368133010
€ 8.00
23
1357741612
ref: 23
ADJUSTER,CABLE
1357741612
€ 8.00
24
1366116600
ref: 24
NUT
1366116600
€ 5.00
25
1338714300
ref: 25
SEAT,RETURN SPRING
€ 5.50
26
1326614300
ref: 26
GASKET,MIXING CHAMBER (NAS)
1326614300
€ 4.00
27
1357314300
ref: 27
SPRING,THROTTLE VALVE
1357314300
€ 7.50
28
1326114300
ref: 28
CAP,CARBURETOR,TOP
€ 14.50
29
1355114300
ref: 29
VALVE,THROTTLE
1355114300
€ 68.00
30
1341143200
ref: 30
13400-14500
VALVE,STARTER
€ 39.00
31
1329515010
ref: 31
09280-08014
O-RING
€ 3.00
32
1338714310
ref: 32
13387-14230
RING
€ 6.00
33
1339814310
ref: 33
PLATE,NEEDLE JET
€ 7.00
34
0211203108
ref: 34
02112-03107
SCREW
0211203108
€ 1.50
35
0832121038
ref: 35
09162-03001
LOCK WASHER
€ 1.50
36-1
0949154001
ref: 36-1
09491-54002
JET
€ 11.50
36-2
0949156001
ref: 36-2
09491-56003
JET
0949156001
€ 14.50
36-3
0949162001
ref: 36-3
09491-62005
JET
€ 10.50
36-4
0949164001
ref: 36-4
09491-64002
JET
€ 8.50
36-5
0949166001
ref: 36-5
09491-66002
JET
0949166001
€ 10.50
37-1
0949400357
ref: 37-1
JET,NEEDLE(R-0)
0949400357
€ 16.50
37-2
0949400356
ref: 37-2
JET,NEEDLE
0949400356
€ 17.00
38-1
0949250010
ref: 38-1
JET,PILOT(50)
0949250010
€ 8.00
38-2
0949260004
ref: 38-2
JET,PILOT
0949260004
€ 7.50
