GEAR CHANGE MECHANISM
RM65 2004 (K4) USA (E03)
Gear change mechanism diagram RM65 2004 (K4) USA (E03)
GEAR CHANGE MECHANISM RM65 2004 (K4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
13156
K131561347
ref: 13156
LEVER,CHANGE,P
€ 81.00
13161
K131611280
ref: 13161
LEVER-COMP-CHANGE SHAFT
€ 64.50
13236
K132361026
ref: 13236
LEVER-COMP,CHANGE DRUM
€ 5.50
13236A
K132361376
ref: 13236A
LEVER-COMP,CHANGE
€ 4.50
13242
K132421366
ref: 13242
LEVER-ASSY-CHANGE,PEDAL,STEEL
€ 28.00
92002
K920021237
ref: 92002
BOLT,6X20
€ 2.50
92009
K920091102
ref: 92009
SCREW,CHANGE LEVER
€ 3.00
92081
K920811109
ref: 92081
SPRING,CHANGE LEVER
€ 3.00
92081A
K920811129
ref: 92081A
SPRING,TENSION
€ 6.00
92081B
K920811275
ref: 92081B
SPRING,CHANGE LEVER
€ 2.50
