CARBURETOR
SP125 1986 (G) USA (E03)
Carburetor diagram SP125 1986 (G) USA (E03)
CARBURETOR SP125 1986 (G) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1320044A10
ref:
CARBURETOR ASSEMBLY (VM20)
€ 0.00
1
1337305230
ref: 1
PLATE,NEEDLE VALVE FITTING
€ 7.00
2
1338747010
ref: 2
RING
€ 7.50
3
1357305230
ref: 3
SPRING,THROTTLE VALVE
€ 0.00
4
1366116600
ref: 4
NUT
€ 5.00
5
1357748110
ref: 5
ADJUSTER,CABLE
€ 8.00
6
1368116600
ref: 6
CAP,RUBBER
€ 7.00
7
1360105230
ref: 7
SCREW
€ 0.00
8
1339410010
ref: 8
CLIP
€ 4.50
9
1338247010
ref: 9
WASHER,JET NEEDLE
€ 3.00
10
1338847010
ref: 10
SPRING
€ 7.00
11
1326736600
ref: 11
SCREW,THROTTLE STOP
€ 8.50
12
1329533010
ref: 12
O RING
€ 4.50
13
1326835010
ref: 13
SPRING
€ 3.00
14
1337346710
ref: 14
PLATE,NEEDLE VALVE FITING
€ 4.50
15
0211203066
ref: 15
02112-0306B
SCREW
€ 2.00
16
1325401010
ref: 16
PIN,FLOAT
€ 3.00
17
1337043250
ref: 17
13370-05320
VALVE ASSEMBLY,NEEDLE
€ 59.50
18
1325005230
ref: 18
FLOAT
€ 24.00
19
0949400507
ref: 19
JET,NEEDLE(N-9)
€ 0.00
20
0949195005
ref: 20
JET,MAIN(95)
€ 8.50
21
1338344A10
ref: 21
NEEDLE JET
€ 0.00
22
1338544A10
ref: 22
PIPE
€ 0.00
23
1325105230
ref: 23
GASKET,FLOAT CHAMBER
€ 0.00
24
1324702340
ref: 24
PLUG,DRAIN
€ 5.50
25
0211204167
ref: 25
02112-0416A
SCREW
€ 1.00
26
0832121047
ref: 26
08321-0104A
WASHER,LOCK 4M
€ 2.00
27
0949222008
ref: 27
JET,PILOT(22.5)
€ 9.50
28
1368418900
ref: 28
09355-30705-600
HOSE
€ 13.50
29
1368422A00
ref: 29
44420-44AR0
HOSE
€ 13.00
30
1324643010
ref: 30
O RING
€ 4.00
31
1355105230
ref: 31
(CA) VALVE,THROTTLE
€ 0.00
32
1341105320
ref: 32
PLUNGER ASSY
€ 18.00
33
1327802330
ref: 33
O RING
€ 2.00
34
1341747070
ref: 34
SPRING
€ 4.00
35
1368231210
ref: 35
CAP,STARTER VALVE
€ 5.00
36
1341805320
ref: 36
HOLDER
€ 7.00
37
1341305230
ref: 37
LEVER
€ 20.50
38
1360122A00
ref: 38
02112-3416B
SCREW
€ 3.00
39
1342105320
ref: 39
PLATE
€ 3.00
40
1343205320
ref: 40
RING
€ 6.00
41
1358947070
ref: 41
WASHER
€ 3.00
42
1342405320
ref: 42
RING
€ 8.00
43
0832121086
ref: 43
08321-0108A
WASHER,LOCK,8.
€ 2.50
