CRANKCASE (MODEL X)
SP500 1981 (X) USA (E03)
Crankcase (model x) diagram SP500 1981 (X) USA (E03)
CRANKCASE (MODEL X) SP500 1981 (X) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1130037400
ref: 1
11300-37410
CRANKCASE SET
€ 969.00
2
0920613001
ref: 2
04211-13189
PIN
€ 2.50
3
0211206608
ref: 3
02112-06607
SCREW 6X60
€ 2.50
4
0211206408
ref: 4
02112-06407
SCREW
€ 2.00
5
0211206308
ref: 5
02112-06307
SCREW 6X30
€ 2.50
6
0928009004
ref: 6
09280-09005
O-RING
€ 4.00
7
0910310033
ref: 7
BOLT(10X70)
€ 5.00
8
0151708508
ref: 8
01550-08507
BOLT
€ 3.50
9
0831931088
ref: 9
08319-3108A
NUT
€ 2.50
10
0910310034
ref: 10
BOLT
€ 3.50
11
0910310035
ref: 11
BOLT
€ 0.00
12
0910310036
ref: 12
BOLT
€ 4.00
13
0831931108
ref: 13
NUT
€ 3.00
14-1
0916910011
ref: 14-1
WASHER
€ 1.00
14-2
0916910012
ref: 14-2
WASHER
€ 1.00
15
1161032400
ref: 15
SPACER
€ 12.00
