REAR SWINGING ARM
TC120 1971 (R) USA (E03)
Rear swinging arm diagram TC120 1971 (R) USA (E03)
REAR SWINGING ARM TC120 1971 (R) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
3
0916010127
ref: 3
WASHER (10.5X24X2.3)
€ 2.00
4
0832201127
ref: 4
WASHER
€ 2.00
5
0831310107
ref: 5
NUT
€ 2.50
7
0931910009
ref: 7
BUSHING(10X23X35)
€ 7.50
8
612112060V
ref: 8
SHAFT,RR SWINGINGARM PIVOT
€ 9.00
10
0832201107
ref: 10
WASHER
€ 2.50
11
0832101107
ref: 11
WASHER,LOCK
€ 2.00
16
0832101087
ref: 16
WASHER,LOCK
€ 2.00
17
0914008008
ref: 17
NUT
€ 1.50
18
0938406001
ref: 18
RETAINER,SNAP
€ 2.50
20
0832201067
ref: 20
WASHER
€ 2.00
22
0832101067
ref: 22
WASHER,LOCK
€ 2.50
23-1
0910006067
ref: 23-1
BOLT(6X14)
€ 2.50
25
4361203001
ref: 25
RUBBER,PILLION FOOTREST
€ 3.50
26
0916019024
ref: 26
WASHER(19.5X32X2)
€ 2.00
27
0920006010
ref: 27
PIN
€ 2.50
29
0915910003
ref: 29
NUT
€ 2.00
30
4360003001
ref: 30
FOOTREST ASSEMBLY,REAR
€ 21.00
31
0831000107
ref: 31
NUT
€ 2.50
