SEAT TAIL BOX (MODEL K2)

TL1000R 2000 (Y) USA (E03)

Seat tail box (model k2) diagram TL1000R 2000 (Y) USA (E03)

SEAT TAIL BOX (MODEL K2) TL1000R 2000 (Y) USA (E03)

SEAT TAIL BOX (MODEL K2) TL1000R 2000 (Y) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

4550002FB0019
ref: 1

BOX ASSY,SEAT TAIL(BLACK)

€ 199.00

2

4555002FA0019
ref: 2

BOX,SEAT TAIL(BLACK)

€ 79.00

3

6816002FB00JW
ref: 3

TAPE SET,BOX SEAT TAIL(WHITE)

€ 61.00

3

6816002FB00JW
ref: 3

TAPE SET,BOX SEAT TAIL(WHITE)

€ 61.00

4

4550002FB0Y9H
ref: 4

BOX ASSY,SEAT TAIL(YELLOW)

€ 0.00

5

4555002FA0Y9H
ref: 5

BOX,SEAT TAIL

€ 79.00

6

6816002FB0YD8
ref: 6

TAPE SET,BOX SEAT TAIL(SILVER)

€ 0.00
