MAGNETO (TS185K
TS185 1976 (A) USA (E03)
Magneto (ts185k diagram TS185 1976 (A) USA (E03)
MAGNETO (TS185K TS185 1976 (A) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
3210029611
ref: 1
MAGNETO ASSEMBLY
€ 142.00
2
3212029611
ref: 2
COIL,LIGHTING
€ 53.00
3
3213029611
ref: 3
COIL
€ 16.50
4
3214032020
ref: 4
32140-32021
COIL
€ 224.50
5
3215032020
ref: 5
COIL,PULSER
€ 210.50
6
0211105357
ref: 6
02112-05357
SCREW 5X35
€ 1.50
7
0211205308
ref: 7
02112-0530A
SCREW
€ 1.50
8
0832121058
ref: 8
08321-0105A
LOCK WASHER
€ 2.00
9
3210229612
ref: 9
ROTOR ASSEMBLY
€ 134.50
10
0914014011
ref: 10
NUT
€ 3.50
11
0832121148
ref: 11
08321-0114A
LOCK WASHER
€ 2.00
12
0916014015
ref: 12
WASHER(14X27X3)
€ 4.00
13
0211205168
ref: 13
02112-05167
SCREW
€ 2.50
14
0832221058
ref: 14
08322-01057
WASHER
€ 2.50
15
0834131049
ref: 15
09420-04008
KEY 4MM
€ 3.50
16
3650029610
ref: 16
REGISTER ASSY,S
€ 24.50
17
0111206108
ref: 17
01500-06107
BOLT
€ 2.00
18
0832121068
ref: 18
08321-01067
LOCK WASHER
€ 2.50
