FRONT MASTER CYLINDER (MODEL K7/K8/K9)

VL1500T BOULEVARD C90 2006 (K6) USA (E03)

Front master cylinder (model k7/k8/k9) diagram VL1500T BOULEVARD C90 2006 (K6) USA (E03)

prices are in EUR

ref

part #

description

quantity

5960010FB1
ref: 1

CYLINDER ASSY,FR MASTER

€ 337.50

5960145810
ref: 2

PISTON/CUP SET

€ 34.00

5966644300
ref: 3

BOOT

€ 6.00

5966710F00
ref: 4

DIAPHRAGM

€ 7.00

5743710F00
ref: 5

PLATE,DIAPHRAGM

€ 13.00

5966910F20
ref: 6

CAP

€ 45.00

0212204127
ref: 7

SCREW

€ 2.00

5967110F10
ref: 8

HOLDER

€ 65.50

0713006207
ref: 9

BOLT

€ 3.50

5966432F00
ref: 10

PROTECTOR

€ 7.50

0925005008
ref: 11

CAP(OD:10)

€ 5.00

12-1

0936010042
ref: 12-1
09360-10062

BOLT UNION

€ 5.00

12-2

0936010062
ref: 12-2

BOLT UNION

€ 5.00

0916110009
ref: 13

WASHER(10X15X1.5)

€ 2.00

14-1

5948010F30
ref: 14-1
59480-10F40

HOSE COMP,FRON

€ 174.00

14-2

5948010F40
ref: 14-2

HOSE,RR BRAKE

€ 174.00

0910306272
ref: 15

BOLT(6X25)

€ 2.00

5926610F10
ref: 16

CLAMP,FR BRAKE HOSE

€ 14.50

5926810F10
ref: 17

CLAMP,FR BRAKE HOSE,R

€ 17.50

5927810F10
ref: 18

CLAMP,FR BRAKE HOSE,L

€ 17.50

0910306222
ref: 19

BOLT(6X12)

€ 2.00
