FRONT CYLINDER HEAD

VL800T BOULEVARD C50 2005 (K5) CALIFORNIA (E33)

Front cylinder head diagram VL800T BOULEVARD C50 2005 (K5) CALIFORNIA (E33)

FRONT CYLINDER HEAD VL800T BOULEVARD C50 2005 (K5) CALIFORNIA (E33)
FRONT CYLINDER HEAD VL800T BOULEVARD C50 2005 (K5) CALIFORNIA (E33)
FRONT CYLINDER HEAD VL800T BOULEVARD C50 2005 (K5) CALIFORNIA (E33)
prices are in EUR
ref
part #
description
quantity
1-1
1110141F00
ref: 1-1
HEAD ASSY,CYLINDER FR
1110141F00
€ 978.50
1-2
1110141FA0
ref: 1-2
HEAD ASSY,CYLINDER FR
€ 1,003.00
2
0920611004
ref: 2
PIN(8.4X11X14)
0920611004
€ 6.00
3
1111538A71
ref: 3
11115-41F70
GUIDE,VALVE
1111538A71
€ 18.50
4
0910306101
ref: 4
BOLT(6X50)
0910306101
€ 2.00
5
0910306102
ref: 5
BOLT(6X55)
0910306102
€ 2.50
5A
0910306102
ref: 5A
BOLT(6X55)
0910306102
€ 2.50
5B
0713006803
ref: 5B
07130-0680B
BOLT
0713006803
€ 3.00
6
1112338A00
ref: 6
GASKET,CYLINDER HEAD WATER (NAS)
1112338A00
€ 2.50
7
1114141F00
ref: 7
GASKET,CYLINDER HEAD FR (NAS)
1114141F00
€ 27.50
8
0910308370
ref: 8
BOLT(8X250)
0910308370
€ 11.00
9
0910310133
ref: 9
BOLT(10X155)
0910310133
€ 7.50
10
0910310134
ref: 10
BOLT(10X165)
0910310134
€ 7.50
11
0916008130
ref: 11
WASHER(8.5X24X1.6)
0916008130
€ 2.00
12-1
0916010060
ref: 12-1
09160-10039
WASHER (10.5X22X2.3)
0916010060
€ 2.50
12-2
0916010039
ref: 12-2
WASHER(10.5X22X2.3)
0916010039
€ 2.50
13-1
0910808144
ref: 13-1
BOLT,STUD
0910808144
€ 4.50
13-2
0142108403
ref: 13-2
TAPEIND
0142108403
€ 2.50
14
0155006253
ref: 14
01550-0625A
BOLT
0155006253
€ 2.50
15
0155006303
ref: 15
01550-0630A
BOLT
0155006303
€ 2.50
16
0155006403
ref: 16
01550-0640A
BOLT
0155006403
€ 2.00
17
0155006403
ref: 17
01550-0640A
BOLT
0155006403
€ 2.00
18
0421113189
ref: 18
PIN
0421113189
€ 2.50
19
0712006303
ref: 19
07120-0630B
BOLT
0712006303
€ 3.00
20
0831610083
ref: 20
08316-1008B
NUT
0831610083
€ 3.00
21-1
1117141F00
ref: 21-1
CAP,CYLINDER HEAD COVER FL
1117141F00
€ 162.00
21-2
1117141FA0
ref: 21-2
CAP,CYLINDER HEAD COVER FR,L
€ 112.00
22
1117241F00
ref: 22
CAP,CYLINDER HEAD COVER FR
1117241F00
€ 113.50
23
1117538A11
ref: 23
CAP,INSPECTION INTAKE
1117538A11
€ 14.50
24
1117638A11
ref: 24
CAP,INSPECTION EXHAUST
1117638A11
€ 14.50
25
1117738A00
ref: 25
GASKET,INSPECTION CAP (NAS)
1117738A00
€ 5.00
26
1117910F10
ref: 26
SPACER,CYL HEAD COVER CAP NO.2
1117910F10
€ 8.00
27
0910806102
ref: 27
BOLT,STUD
€ 3.00
28
0916006084
ref: 28
WASHER(6.5X18X1.6)
0916006084
€ 2.00
29
0916009016
ref: 29
WASHER(9.5X20X1)
0916009016
€ 2.00
30
0924130004
ref: 30
PLUG(OD:30)
0924130004
€ 6.50
31
0932009016
ref: 31
CUSHION
0932009016
€ 2.50
32
0932013015
ref: 32
CUSHION
0932013015
€ 3.00
33
0154706203
ref: 33
01547-0620B
SCREW
0154706203
€ 2.50
34
0154706507
ref: 34
BOLT
0154706507
€ 2.50
35-1
0831320063
ref: 35-1
08313-2006A
NUT
0831320063
€ 2.00
35-2
0915906093
ref: 35-2
NUT
€ 2.00
36-1
0948200354
ref: 36-1
PLUG,SPARK(DPR7EA-9)
0948200354
€ 4.00
36-2
0948200355
ref: 36-2
09482-00354
SPARK PLUG X22E
€ 4.00
36-3
0948200330
ref: 36-3
PLUG,SPARK(DPR9EA-9)
0948200330
€ 4.00
36-4
0948200331
ref: 36-4
PLUG,SPARK(X27EPR-U9)
€ 4.00
36-5
0948200334
ref: 36-5
PLUG,SPARK(DPR8EA-9)
€ 4.00
36-6
0948200335
ref: 36-6
PLUG,SPARK(X24EPR-U9)
€ 4.00
37-1
1118145C10
ref: 37-1
UNION,WATER OUTLET
1118145C10
€ 33.00
37-2
1118141F00
ref: 37-2
UNION,CYL HEAD OUTLET
€ 31.50
38
1118238A00
ref: 38
GASKET,WATER OUTLET UNION (NAS)
1118238A00
€ 2.00
39-1
0155006203
ref: 39-1
01550-0620A
BOLT
0155006203
€ 2.50
39-2
0713006203
ref: 39-2
07130-0620B
BOLT,CRKCASE,R
0713006203
€ 3.00
40
0930108007
ref: 40
BUSH
0930108007
€ 4.00
41-1
1789141F00
ref: 41-1
17891-41F10
UNION,CYL HEAD
€ 11.50
41-2
1789141F10
ref: 41-2
UNION,CYL HEAD JOINT
1789141F10
€ 11.50
42
0713006123
ref: 42
07130-0612A
BOLT,STRANGER
€ 2.50
43
0928016005
ref: 43
O RING(D:2.4,ID:15.8)
0928016005
€ 1.50
44-1
1785441F00
ref: 44-1
17854-41F01
HOSE,CYL HEAD
€ 12.00
44-2
1785441F01
ref: 44-2
HOSE,CYLINDER HEAD JOINT
1785441F01
€ 12.00
45
0940228511
ref: 45
CLAMP
0940228511
€ 8.50
46
1365057F00
ref: 46
SENSOR,WATER TEMP
1365057F00
€ 35.50
47
0916812017
ref: 47
GASKET(12X17X1) (NAS)
0916812017
€ 2.00
