prices are in EUR
ref
part #
description
quantity
1-1
SWING ARM ASSEMBLY,REAR
1-2
SWING ARM ASSEMBLY,REAR
1-3
SWING ARM ASSEMBLY,REAR
1-5
SWING ARM ASSEMBLY,REAR
1-8
SWING ARM ASSEMBLY,REAR
2
BEARING(22X29X30)
3
SPACER,RR SWGARM PIVOT CTR
4
SPACER,RR SWGARM PIVOT
5-1
COVER,RR SWGARM DUST SEAL
5-2
SEAL,RR SWGARM PIVOT DUST
6
WASHER
7
SHAFT,RR SWINGINGARM PIVOT
8
NUT
9
CAP,RR SWINGING ARM PIVOT,R
10-1
COVER,RR SWGARM PIVOT,L
10-2
COVER COMP,REAR SWING ARM PIVOT
10-3
COVER COMP,REAR SWING ARM PIVOT
10-4
COVER,REAR SWING ARM PIVOT,LEFT (
10-5
COVER,REAR SWING ARM PIVOT
10-6
COVER,RR SWGARM PIVOT,L
10-7
COVER,RR SWGARM PIVOT,L(BLACK)
10-8
COVER,REAR SWING ARM PIVOT
11
BOOT,PROPELLER SHAFT
12
CLAMP
13-1
SCREW 4X25
13-2
SCREW
14
ABSORBER ASSEMBLY,REAR SHOCK
15-1
WASHER
15-2
WASHER (10.1X21X2.3)
16-2
NUT
17
CAP,FRAME HANDLE GRIP
18
BOLT(10X39)
20
WASHER
21-1
NUT
21-2
NUT
22
WASHER 10MM
