FRONT BRAKE HOSE

VS800GL 1992 (N) (E01 E02 E04 E16 E17 E18 E21 E22 E25 E34 39 53)

Front brake hose diagram VS800GL 1992 (N) (E01 E02 E04 E16 E17 E18 E21 E22 E25 E34 39 53)

prices are in EUR

ref

part #

description

quantity

1-1

0936010017
ref: 1-1
MODEL N/P

BOLT UNION

€ 6.50

1-2

0936010039
ref: 1-2
MODEL R/S/T/V

BOLT UNION

€ 6.50

0916110009
ref: 2

WASHER(10X15X1.5)

€ 2.00

5948038A63
ref: 3

HOSE,FR BRAKE

€ 221.00

5929043500
ref: 4

ADAPTER,BRAKE HOSE

€ 34.50

5926838A22
ref: 5

GUIDE,BRAKE HOSE

€ 7.50
