prices are in EUR
ref
part #
description
quantity
1-4
SWING ARM,REAR (BLACK)
1-5
SWING ARM,REAR (MAROON)
1-6
SWING ARM,REAR (GREEN)
2
BEARING(22X29X20)
3
SPACER,RR SWGARM PIVOT
4
SPACER,RR SWGARM PIVOT
5
SEAL,RR SWGARM PIVOT DUST
6
WASHER
7
SAHFT,RR SWGARM PIVOT
8
WASHER(17X30X3)
9
NUT 16MM
10
CAP,RR SWINGING ARM PIVOT,R
11-1
COVER,REAR SWING ARM PIVOT
11-2
COVER,RR SWGARM PIVOT,L(RED)
11-3
COVER,REAR SWING ARM PIVOT
11-4
COVER,RR SWGARM PIVOT,L
11-5
COVER,REAR SWING ARM PIVOT
11-6
COVER,REAR SWING ARM PIVOT
12
BOOT,PROPELLER SHAFT
13
CLAMP
14-1
SCREW 4X25
14-2
SCREW
15
TORQUELINK,RR
16
BOLT(10X28)
17-1
WASHER
17-2
WASHER (10X20X2.3)
18-1
NUT
18-2
NUT
18-3
NUT
18-4
NUT
20
BOLT(10X41)
21
WASHER (10X20X2.3)
22
PIN 16X20
23-1
CAP
23-2
CAP
25
ABSORBER ASSEMBLY,REAR SHOCK
26-1
WASHER
26-2
WASHER (10.1X21X2.3)
27-2
NUT
28
BOLT(10X39)
30
WASHER
31-1
NUT
31-2
NUT
32
WASHER 10MM
33
CAP,FRAME HANDLE GRIP
