REAR CUSHION LEVER

DR-Z400SM 2006 (K6) USA (E03) DRZ400SM DR Z400SM

Rear cushion lever diagram DR-Z400SM 2006 (K6) USA (E03) DRZ400SM DR Z400SM

REAR CUSHION LEVER DR-Z400SM 2006 (K6) USA (E03) DRZ400SM DR Z400SM
REAR CUSHION LEVER DR-Z400SM 2006 (K6) USA (E03) DRZ400SM DR Z400SM
REAR CUSHION LEVER DR-Z400SM 2006 (K6) USA (E03) DRZ400SM DR Z400SM
prices are in EUR
ref
part #
description
quantity
1
6260037830
ref: 1
LEVER SET,RR CUSHION
€ 215.50
2
0926320086
ref: 2
BEARING(20X27X15)
0926320086
€ 12.50
3
0926316033
ref: 3
BEARING(16X22X12)
0926316033
€ 19.00
4
6262414500
ref: 4
SEAL,CUSHION LEVER DUST
6262414500
€ 3.50
5
6264737E00
ref: 5
WASHER,THRUST SWINGARM RR
6264737E00
€ 3.00
6
0928416005
ref: 6
SEAL,OIL(16X22X2.5)
0928416005
€ 5.50
7
6268537E00
ref: 7
WASHER,THRUST LVR CUSHION RR
6268537E00
€ 3.00
8
6231737E10
ref: 8
SPACER,CUSHION LEVER FR
6231737E10
€ 12.00
9
6265837E01
ref: 9
BOLT,RR CUSHION LEVER FR
6265837E01
€ 10.00
10
0915912056
ref: 10
NUT
0915912056
€ 7.00
11
6264637E10
ref: 11
SPACER,RR CUSHION
6264637E10
€ 12.50
12
6262137E01
ref: 12
BOLT,RR CUSHION
6262137E01
€ 9.00
13
0915912056
ref: 13
NUT
0915912056
€ 7.00
14
6268436E10
ref: 14
SPACER,RR CUSHION LEVER RR
6268436E10
€ 7.50
15
6264037E11
ref: 15
ROD SET,RR CUSHION
€ 116.50
16
6264637E10
ref: 16
SPACER,RR CUSHION
6264637E10
€ 12.50
17
6264737E00
ref: 17
WASHER,THRUST SWINGARM RR
6264737E00
€ 3.00
18
6262137E01
ref: 18
BOLT,RR CUSHION
6262137E01
€ 9.00
19
0915912056
ref: 19
NUT
0915912056
€ 7.00
