HANDLEBAR
DR650SE 2014 (L4) USA (E03)
Handlebar diagram DR650SE 2014 (L4) USA (E03)
HANDLEBAR DR650SE 2014 (L4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5611032E00291
ref: 1
HANDLEBAR(BLACK)
€ 63.00
2
5620029831
ref: 2
BALANCER SET,HANDLEBAR
€ 17.50
3
021220660B
ref: 3
SCREW
€ 3.00
4
0916006131
ref: 4
WASHER(6.5X16X4)
€ 2.50
5
5627210G20
ref: 5
EXPANDER,HANDLE BALANCER
€ 3.50
6
5627310G10
ref: 6
NUT,HANDLE BALANCER
€ 6.50
7
5650006G30
ref: 7
MIRROR ASSY,RR VIEW,R
€ 101.50
8
5660006G30
ref: 8
MIRROR ASSY,RR VIEW,L
€ 102.50
9
5820032E01
ref: 9
CABLE ASSY,CLUTCH
€ 40.50
10
5827331000
ref: 10
BOOT,CLUTCH CABLE
€ 2.50
11
5863432E00
ref: 11
STOPPER,CLUTCH CABLE
€ 9.50
12
0940309307
ref: 12
CLAMP
€ 2.50
13
5830032E00
ref: 13
CABLE ASSY,THROTTLE
€ 82.00
14
5841032E00
ref: 14
CABLE,STARTER
€ 25.50
15
0940800066
ref: 15
CLIP
€ 1.50
16
0940725401
ref: 16
CLAMP(L:235)
€ 4.00
17
015500612B
ref: 17
BOLT
€ 2.50
