REAR FENDER

GP100 1978 (C) (E01 E02 E06 E13 E14 E24 E30)

Rear fender diagram GP100 1978 (C) (E01 E02 E06 E13 E14 E24 E30)

REAR FENDER GP100 1978 (C) (E01 E02 E06 E13 E14 E24 E30)

REAR FENDER GP100 1978 (C) (E01 E02 E06 E13 E14 E24 E30)

prices are in EUR

ref

part #

description

quantity

1-1

6311239100
ref: 1-1
TO 63112-39101

BODY, REAR FENDER FRONT

€ 37.00

2-1

6311039100
ref: 2-1

BODY, REAR FENDER REAR

€ 108.00

3

0916006007
ref: 3

WASHER

€ 2.00

4

0932006006
ref: 4

CUSHION

€ 1.50

5

0110706128
ref: 5

BOLT

€ 2.00

6

0832121068
ref: 6

LOCK WASHER

€ 2.50

7

0110708478
ref: 7

BOLT

€ 0.00

8

0832121088
ref: 8

LOCK WASHER

€ 2.00
