prices are in EUR
ref
part #
description
quantity
2
BUSH
3
GEAR,SECOND DRIVE
4-1
GEAR,THIRD & FOURTH DRIVE,N
4-2
GEAR,THIRD & FOURTH DRIVE,N
5-1
GEAR,FIFTH DRIVE
6
CIRCLIP
7
BEARING(20X47X14)
8
BEARING
9
RETAINER,DRIVE SHAFT BEARING
11-1
SHAFT,DRIVE
11-2
SHAFT,DRIVE
12
GEAR,FIRST DRIVEN
13
WASHER
14
BEARING(15X19X7.8)
15
GEAR,SECOND DRIVEN
16
CIRCLIP
18
WASHER,LOCK
21
WASHER,OIL SEALING
22
WHEEL,SLIDING DOG
23
BEARING(15X33X12)
24
BEARING(20X47X14)
25
RETAINER,DRIVE SHAFT BEARING
26
SCREW
27
SEAL,OIL(27X40X6)
28-1
PLATE,DRIVESHAFT OIL
28-2
RETAINER,DRIVESHAFT O
30
GEAR,KICK STARTER IDLE(NT:26)
31
WASHER
32
WASHER
33
CIRCLIP,15MM
34
SPROCKET,ENGINE
35
SPACER
36
O RING(D:2.4,ID:19)
37
NUT
38
WASHER,LOCK
40-2
JOINT(RK)
