RIGHT HANDLE SWITCH (MODEL J)

GS450E 1988 (J) (E04 E22 E34 E75 E77)

Right handle switch (model j) diagram GS450E 1988 (J) (E04 E22 E34 E75 E77)

RIGHT HANDLE SWITCH (MODEL J) GS450E 1988 (J) (E04 E22 E34 E75 E77)

RIGHT HANDLE SWITCH (MODEL J) GS450E 1988 (J) (E04 E22 E34 E75 E77)

prices are in EUR

ref

part #

description

quantity

1

5711049510
ref: 1

GRIP,THROTTLE

€ 33.00

2

5742049101
ref: 2

LEVER,BRAKE

€ 36.50

3

5743149100
ref: 3

BOLT,LEVER PIVOT

€ 6.00

4

0831921065
ref: 4

NUT

€ 2.50

5

3720044400
ref: 5

SWITCH ASSY, HANDLE RH

€ 76.50

6

0211205455
ref: 6

SCREW, 5X45

€ 4.00

7

5746033700
ref: 7

SWITCH ASSY,STOP

€ 38.50

8

5746518601
ref: 8

CONTACT,SWITCH

€ 4.50

9

5748133010
ref: 9

COVER,FR BK TERMINAL BASE

€ 19.50

10

0912503105
ref: 10

SCREW

€ 2.50

11

0940712402
ref: 11

CLAMP(L:120)

€ 3.00
