REAR BRAKE
GS650M 1983 (D) USA (E03)
Rear brake diagram GS650M 1983 (D) USA (E03)
REAR BRAKE GS650M 1983 (D) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
4311034310
ref: 1
PEDAL,BRAKE
€ 19.00
2
4312034300
ref: 2
ARM,BRAKE PEDAL ROD
€ 0.00
3
0920006029
ref: 3
PIN
€ 1.50
4
0832221068
ref: 4
08322-01067
WASHER
€ 2.00
5
0411120158
ref: 5
04111-2015A
PIN
€ 1.50
6
0110708258
ref: 6
01500-08257
BOLT
€ 2.50
7
0832121088
ref: 7
08321-01087
LOCK WASHER
€ 2.00
8
0944314013
ref: 8
SPRING
€ 21.50
9
0110706208
ref: 9
01500-06207
BOLT
€ 2.00
10
0831011068
ref: 10
08310-00067
NUT
€ 2.50
