STAND
GSF1200S BANDIT 2004 (K4) USA (E03)
Stand diagram GSF1200S BANDIT 2004 (K4) USA (E03)
STAND GSF1200S BANDIT 2004 (K4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
4231032F00
ref: 1
42310-32F01
STAND,COMP,PRO
€ 154.50
2
0944312048
ref: 2
SPRING
€ 22.00
3
0944319010
ref: 3
SPRING
€ 6.00
4
0911110058
ref: 4
BOLT(10X37.5)
€ 6.00
5
4232103FK0
ref: 5
NUT,PROP STAND
€ 4.50
6
4311131E01
ref: 6
PEDAL,BRAKE
€ 100.50
7
0916018022
ref: 7
WASHER(18X24X1)
€ 3.00
8
4356032C00
ref: 8
BRACKET,STOP LAMP SWITCH SPR
€ 3.00
9
0211205163
ref: 9
02112-0516A
SCREW
€ 2.00
10
0944313029
ref: 10
SPRING
€ 5.00
11
4326117C00
ref: 11
TUBE,BRAKE SPRING GUIDE
€ 5.50
12
4210031F00
ref: 12
STAND,CTR
€ 213.50
13
0910310126
ref: 13
BOLT(10X48)
€ 4.50
14
0918010113
ref: 14
SPACER(10X16X25.5)
€ 13.50
15
0944314059
ref: 15
SPRING
€ 9.50
16
0944322013
ref: 16
SPRING OUTER
€ 7.00
17
0932110034
ref: 17
CUSHION
€ 6.50
