STARTING MOTOR

GSF1250SA BANDIT 2008 (K8) CALIFORNIA (E33)

Starting motor diagram GSF1250SA BANDIT 2008 (K8) CALIFORNIA (E33)

prices are in EUR

ref

part #

description

quantity

3110018H00
ref: 1
31100-18H10

MOTOR ASSY,STARTING

€ 546.00

3117518H00
ref: 2

FRAME ASSY

€ 126.50

3126431300
ref: 3
31264-32E00

O RING

€ 7.50

3115018H00
ref: 4

HOUSING ASSY

€ 109.50

0928024003
ref: 5

O RING(D:3,ID:24.5)

€ 2.00

3128118H00
ref: 6

BOLT

€ 23.50

3114349040
ref: 7

O RING

€ 3.00

0912806024
ref: 8
09103-06212

SCREW (6X25)

€ 2.50

0910306212
ref: 8A

BOLT(6X25)

€ 2.50

083613506A
ref: 9

NUT

€ 2.00
