CRANKCASE
GSX1300RZ HAYABUSA 1999 (X) USA (E03)
Crankcase diagram GSX1300RZ HAYABUSA 1999 (X) USA (E03)
CRANKCASE GSX1300RZ HAYABUSA 1999 (X) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
1130124841
ref: 1-1
11301-24849
CRANKCASE SET
€ 1,917.00
1-1
1130124841
ref: 1-1
11301-24849
CRANKCASE SET
€ 1,917.00
1-2
1130124843
ref: 1-2
11301-24849
CRANKCASE SET
€ 1,917.00
1-2
1130124843
ref: 1-2
11301-24849
CRANKCASE SET
€ 1,917.00
1-3
1130124844
ref: 1-3
11301-24849
CRANKCASE SET
€ 1,917.00
1-4
1130124845
ref: 1-4
11301-24849
CRANKCASE SET
€ 1,917.00
1-5
1130224810
ref: 1-5
11302-24813
CRANKCASE SET
€ 2,925.50
1-6
1130224811
ref: 1-6
11302-24813
CRANKCASE SET
€ 2,925.50
2
1131933E50
ref: 2
PIN,CRANKCASE
€ 4.00
3
1132324F00
ref: 3
SEPARATOR,OIL
€ 28.50
4
0154706253
ref: 4
01547-0625B
SCREW
€ 2.50
5
1132824F00
ref: 5
UNION,BREATHER
€ 12.00
6
0916810031
ref: 6
GASKET(10.2X20X2).3 (NAS)
€ 2.00
6
0916810031
ref: 6
GASKET(10.2X20X2).3 (NAS)
€ 2.00
7
0154706123
ref: 7
01547-0612B
BOLT
€ 2.00
8
0910309008
ref: 8
BOLT(9X95)
€ 6.00
9
0910309010
ref: 9
BOLT(9X115)
€ 6.00
10
0916808016
ref: 10
GASKET(8.2X14X1) (NAS)
€ 1.00
11
0154706503
ref: 11
01547-0650B
BOLT
€ 3.50
12
0155008653
ref: 12
01550-0865A
BOLT
€ 3.00
13
0155008803
ref: 13
01550-0880A
BOLT (8X80)
€ 4.00
14
0155010603
ref: 14
01550-1060A
BOLT
€ 4.00
15
0154706403
ref: 15
01547-0640B
BOLT
€ 3.00
15A
0154706403
ref: 15A
01547-0640B
BOLT
€ 3.00
16
0154706603
ref: 16
01547-0660B
BOLT
€ 3.50
17-1
0155008603
ref: 17-1
01550-0860A
BOLT
€ 3.50
17-2
0910308155
ref: 17-2
BOLT(8X60)
€ 3.00
18-1
0155008503
ref: 18-1
01550-0850B
BOLT
€ 2.50
18-2
0910308355
ref: 18-2
BOLT(8X50)
€ 3.00
19
1139333E01
ref: 19
JET,MAGNETO COOLING
€ 14.00
20
0949320012
ref: 20
JET,AIR(100)
€ 12.00
21
0916806023
ref: 21
GASKET(5.8X13X1.2) (NAS)
€ 2.00
22
0712006123
ref: 22
07120-0612B
BOLT
€ 3.50
23
1139034E00
ref: 23
JET,PISTON COOLINGR
€ 13.50
24
1139034E10
ref: 24
JET,PISTON COOLING
€ 13.50
25
0928004004
ref: 25
O RING(D:1.2,ID:4)
€ 2.00
26
0910606075
ref: 26
BOLT(6X12)
€ 2.50
27
0910606076
ref: 27
BOLT(6X10)
€ 2.50
28
0949336006
ref: 28
JET,AIR(180)
€ 11.50
29
1153246E00
ref: 29
JET,OIL PAN GALLERY
€ 7.50
30
0712006123
ref: 30
07120-0612B
BOLT
€ 3.50
31
0916806023
ref: 31
GASKET(5.8X13X1.2) (NAS)
€ 2.00
32
0713008163
ref: 32
07130-0816A
BOLT
€ 3.00
33
0916808016
ref: 33
GASKET(8.2X14X1) (NAS)
€ 1.00
34
0924810010
ref: 34
PLUG(10X10)
€ 4.00
35
0916810002
ref: 35
GASKET(10X14X3.6) (NAS)
€ 2.00
36
0924816012
ref: 36
PLUG,16X8
€ 4.50
37
0916816002
ref: 37
GASKET(16X22X2) (NAS)
€ 2.00
38-1
0924814005
ref: 38-1
PLUG,14X12
€ 5.00
38-2
0924814005
ref: 38-2
PLUG,14X12
€ 5.00
38-3
0924814011
ref: 38-3
09248-14005
PLUG
€ 5.00
39-1
0916814011
ref: 39-1
GASKET(14X20X1.5) (NAS)
€ 2.00
39-2
0916814002
ref: 39-2
09168-14004
GASKET(13.8X18.8X4.8) (NAS)
€ 2.50
39-3
0916814002
ref: 39-3
09168-14004
GASKET(13.8X18.8X4.8) (NAS)
€ 2.50
40
1659106B00
ref: 40
16591-06B01
UNION,OIL STAND
€ 6.00
41
1222824F000D0
ref: 41
BEARING,CRANK THRUST,L
€ 8.50
41
1222824F000D0
ref: 41
BEARING,CRANK THRUST,L
€ 8.50
41
1222824F000D0
ref: 41
BEARING,CRANK THRUST,L
€ 8.50
42-1
1222824F000A0
ref: 42-1
BEARING,CRANK THRUST,L
€ 8.50
42-1
1222824F000A0
ref: 42-1
BEARING,CRANK THRUST,L
€ 8.50
42-1
1222824F000A0
ref: 42-1
BEARING,CRANK THRUST,L
€ 8.50
42-2
1222824F000B0
ref: 42-2
BEARING,CRANK THRUST,L
€ 8.50
42-3
1222824F000C0
ref: 42-3
BEARING,CRANK THRUST,L
€ 8.50
42-4
1222824F000D0
ref: 42-4
BEARING,CRANK THRUST,L
€ 8.50
42-4
1222824F000D0
ref: 42-4
BEARING,CRANK THRUST,L
€ 8.50
42-5
1222824F000E0
ref: 42-5
BEARING,CRANK THRUST,L
€ 8.50
42-5
1222824F000E0
ref: 42-5
BEARING,CRANK THRUST,L
€ 8.50
42-6
1222824F000F0
ref: 42-6
BEARING,CRANK THRUST,L
€ 8.50
43
1651034E00
ref: 43
16510-07J00
FILTER ASSEMBLY,ENGINE OIL
€ 12.50
44-1
0910012076
ref: 44-1
BOLT 12X295
€ 25.50
44-2
0910312066
ref: 44-2
BOLT(12X320)
€ 33.00
45-1
0910012075
ref: 45-1
BOLT(12X240)
€ 19.00
45-2
0910312067
ref: 45-2
BOLT(12X243)
€ 29.00
46
0915912054
ref: 46
NUT
€ 8.00
47
1161124F00
ref: 47
SPACER,ENG MTG(L47)
€ 16.00
48
0832201127
ref: 48
WASHER
€ 2.00
49-1
3782033D00
ref: 49-1
37820-33D10
SWITCH ASSEMBLY,OIL PRESSURE
€ 29.00
49-2
3782033D10
ref: 49-2
SWITCH ASSY,OIL PRESSURE
€ 29.00
