EVAP SYSTEM (E33)

GSX1300RZ HAYABUSA 1999 (X) USA (E03)

Evap system (e33) diagram GSX1300RZ HAYABUSA 1999 (X) USA (E03)

EVAP SYSTEM (E33) GSX1300RZ HAYABUSA 1999 (X) USA (E03)

EVAP SYSTEM (E33) GSX1300RZ HAYABUSA 1999 (X) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

4443424F00
ref: 1
44400-19810

HOSE,TANK & BREATHER VALVE

€ 7.00

2

0944013041
ref: 2

SPRING

€ 3.50

3

0940111413
ref: 3

CLIP

€ 2.50

4

4424017C00
ref: 4

VALVE,FUEL TANK BREATHER

€ 40.00

5

4489024F00
ref: 5

PLATE,TANK BREATHER VALVE

€ 9.50

6

4489424A00
ref: 6

CUSHION

€ 1.50

7

0214206103
ref: 7
02142-0610A

SCREW 6X10

€ 2.00

8

4489224A00
ref: 8

PLATE,FUEL TANK BREATHER NO.2

€ 3.00

9

4489424A00
ref: 9

CUSHION

€ 1.50

10

0214204083
ref: 10
02142-0408B

SCREW

€ 1.50

11

0935554116600
ref: 11

HOSE(5.4X11.4X600)

€ 12.00

11

0935554116600
ref: 11

HOSE(5.4X11.4X600)

€ 12.00

12

0944013051
ref: 12

SPRING

€ 14.50

13

4424024F00
ref: 13

VALVE,2 WAY & BREATHER VALVE

€ 44.50

14

0916006077
ref: 14

WASHER(6.5X20X1.2)

€ 2.00

15

0155006163
ref: 15
01550-0616A

BOLT

€ 2.50

16

1721026E00
ref: 16

CANISTER ASSY,CHARCOAL

€ 261.50

17

0925107003
ref: 17

CAP,OD:11.5

€ 2.00

18

4488326E00
ref: 18

CUSHION,CANISTER

€ 9.00

19

4488024F00
ref: 19

BRACKET,CANISTER

€ 0.00

20

0155006123
ref: 20
01550-0612A

BOLT

€ 2.50

21

4488226E00
ref: 21

HOLDER,CANISTER

€ 8.00

22

0214206103
ref: 22
02142-0610A

SCREW 6X10

€ 2.00

23

0935554116600
ref: 23

HOSE(5.4X11.4X600)

€ 12.00

24

0944013041
ref: 24

SPRING

€ 3.50

25

0935954111600
ref: 25

HOSE(5.4X11.4X600)

€ 22.00

26

0944013053
ref: 26

SPRING

€ 7.00

27

0940112404
ref: 27

CLIP

€ 2.50

28

0936406005
ref: 28

UNION

€ 4.00
