CRANKCASE COVER

ref

part #

description

quantity

1-1

1134024F00
ref: 1-1
11340-24F01

COVER COMP,CLUTCH

€ 198.50

1-2

1134024F01
ref: 1-2

COVER,CLUTCH

€ 198.50

2

1197133210
ref: 2

LENS,OIL LEVEL CHECK

€ 13.50

3

1148224F00
ref: 3

GASKET,CL COVER (NAS)

€ 17.00

4

0421109189
ref: 4

PIN

€ 2.00

5-1

0154706307
ref: 5-1

BOLT

€ 2.50

5-2

0910306213
ref: 5-2

BOLT(6X30)

€ 2.50

6-1

0925920008
ref: 6-1
09259-20008-XC0

PLUG

€ 6.50

6-2

1197125D00
ref: 6-2

PLUG,ENGINE OIL FILLER

€ 5.50

7

0928017003
ref: 7

O RING(D:3.1,ID:16.8)

€ 2.00

8

1137124F00
ref: 8

COVER,CLUTCH OUTER

€ 42.50

9

1137224F00
ref: 9

CUSHION,CLUTCH OUTER COVER

€ 9.50

10

0913906107
ref: 10

SCREW(6X16)

€ 4.00

10A

1137324F00
ref: 10A

WASHER,CLUTCH OUTER COV SCREW

€ 3.00

11-1

1138024F01
ref: 11-1

COVER,STARTER CLUTCH

€ 238.00

11-2

1138024F20
ref: 11-2

COVER,STARTER CLUTCH

€ 174.00

12-1

1149124F00
ref: 12-1
11491-24F01

GASKET,STARTER CLUTCH COVER (NAS)

€ 9.00

12-2

1149124F01
ref: 12-2

GASKET,STARTER CLUTCH COVER (NAS)

€ 9.00

13

0421109149
ref: 13

PIN

€ 2.00

14-1

0154706257
ref: 14-1

BOLT

€ 2.50

14A-1

0154706357
ref: 14A-1

BOLT

€ 2.50

14-2

0910306212
ref: 14-2

BOLT(6X25)

€ 2.50

14A-2

0910306214
ref: 14A-2

BOLT(6X35)

€ 2.50

15

0916806023
ref: 15

GASKET(5.8X13X1.2) (NAS)

€ 2.00

16-1

092593601620H
ref: 16-1

PLUG(SILVER)

€ 10.50

16-2

0925936021
ref: 16-2

PLUG

€ 11.00

17

0928033004
ref: 17

O RING(D:3.1,ID:32.7)

€ 2.50

18

0924816012
ref: 18

PLUG,16X8

€ 4.50

19

0916816002
ref: 19

GASKET(16X22X2) (NAS)

€ 2.00

20-1

1138224F00
ref: 20-1

CAP,STARTER IDLE GEAR

€ 77.50

20-2

1138224F20
ref: 20-2

CAP,STARTER IDLE GEAR

€ 46.00

21

1149224F00
ref: 21

GASKET,START IDLE GEAR CAP (NAS)

€ 6.50

22

0421109149
ref: 22

PIN

€ 2.00

23-1

0154706257
ref: 23-1

BOLT

€ 2.50

23-2

0910306212
ref: 23-2

BOLT(6X25)

€ 2.50

24-1

0154706357
ref: 24-1

BOLT

€ 2.50

24-2

0910306214
ref: 24-2

BOLT(6X35)

€ 2.50

25

1135124F00
ref: 25

COVER,MAGNETO

€ 73.00

26

1148324F00
ref: 26

GASKET,MAGNETO COVER (NAS)

€ 10.00

27

0421109149
ref: 27

PIN

€ 2.00

28-1

0154706307
ref: 28-1

BOLT

€ 2.50

28-2

0910306213
ref: 28-2

BOLT(6X30)

€ 2.50

29A

1136224F00
ref: 29A

PROTECTOR,ENGINE SPRKT COVER

€ 5.00

29-1

1136124F00
ref: 29-1

COVER,ENGINE SPROCKET

€ 134.00

29-2

1136124F10
ref: 29-2

COVER,ENGINE SPROCKET

€ 134.00

30

0421109149
ref: 30

PIN

€ 2.00

31-1

0154706407
ref: 31-1

BOLT

€ 2.50

31-2

0910306215
ref: 31-2

BOLT(6X40)

€ 2.00

32-1

0154706557
ref: 32-1

BOLT

€ 2.50

32-2

0910306216
ref: 32-2

BOLT(6X55)

€ 2.50

33

1138324F00
ref: 33

COVER,GEAR SHIFT

€ 74.50

34

1148524F00
ref: 34

GASKET,GEAR SHIFT COVER (NAS)

€ 7.00

35

0421109149
ref: 35

PIN

€ 2.00

36

0154706253
ref: 36
01547-0625B

SCREW

€ 2.50

37

0154706353
ref: 37
01547-0635B

BOLT

€ 3.00

38

1133024F01
ref: 38

COVER,BREATHER

€ 30.00

38A

0936412002
ref: 38A

UNION

€ 9.50

39-1

1131824F00
ref: 39-1
11318-24F01

GASKET,BREATHER COVER ( (NAS)

€ 6.00

39-2

1131824F01
ref: 39-2

GASKET,BREATHER COVER (NAS)

€ 6.00

40-1

0154706303
ref: 40-1
01547-0630B

BOLT,G/S SWITC

€ 3.00

40-2

0154706303
ref: 40-2
01547-0630B

BOLT,G/S SWITC

€ 3.00

41

0154706503
ref: 41
01547-0650B

BOLT

€ 3.50

42

1133424F00
ref: 42

BRACKET,OIL RETURN TANK

€ 9.50

43

1133002F01
ref: 43

TANK,OIL RETURN

€ 72.00

44

0155006123
ref: 44
01550-0612A

BOLT

€ 2.50

45

1133224F00
ref: 45

HOSE,BREATHER

€ 9.00

46

0940115101
ref: 46

CLIP

€ 2.00

47

1139024F00
ref: 47

HOSE,OIL DRAIN

€ 21.00

48

0940316307
ref: 48

CLAMP

€ 2.00
