CYLINDER HEAD
GSX1300RZ HAYABUSA 2003 (K3) USA (E03)
Cylinder head diagram GSX1300RZ HAYABUSA 2003 (K3) USA (E03)
CYLINDER HEAD GSX1300RZ HAYABUSA 2003 (K3) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1110024F00
ref: 1
HEAD ASSY,CYLINDER
€ 3,235.50
2
0910306026
ref: 2
BOLT(6X39)
€ 2.00
3
0910306165
ref: 3
BOLT(6X45)
€ 2.50
4
0920608007
ref: 4
PIN(6.2X8X16)
€ 2.50
5
1111514D71
ref: 5
GUIDE,VALVE
€ 19.50
6
1114124F00
ref: 6
GASKET,CYLINDER HEAD (NAS)
€ 95.50
7
0421111169
ref: 7
PIN
€ 2.00
8
0155006303
ref: 8
01550-0630A
BOLT
€ 2.50
9
0910310276
ref: 9
BOLT(10X175)
€ 13.50
10
0916010082
ref: 10
WASHER(10.5X19X2)
€ 2.00
11
0712006123
ref: 11
07120-0612B
BOLT
€ 3.50
12
0712006503
ref: 12
07120-0650B
BOLT,CYL.OIL P
€ 2.50
13
0916806023
ref: 13
GASKET(5.8X13X1.2) (NAS)
€ 2.00
14
1113133E00
ref: 14
PIPE,CYLINDER HEAD OIL
€ 33.00
15
0155006353
ref: 15
01550-0635A
BOLT
€ 2.50
16
0155006453
ref: 16
01550-0645A
BOLT (6X45)
€ 2.50
17
0832201063
ref: 17
08322-0106B
WASHER
€ 2.00
18-1
0948200458
ref: 18-1
PLUG,SPARK(NGK CR9E)
€ 8.50
18-2
0948200459
ref: 18-2
PLUG,SPARK(U27ESR-N)
€ 8.50
18-3
0948200456
ref: 18-3
PLUG,SPARK(CR8E)
€ 7.00
18-4
0948200460
ref: 18-4
PLUG,SPARK(CR10E)
€ 8.50
18-5
0948200457
ref: 18-5
PLUG,SPARK(U24ESR-N)
€ 7.00
18-6
0948200461
ref: 18-6
PLUG,SPARK(U31ESR-N)
€ 8.50
19
1311124F00
ref: 19
PIPE,INTAKE
€ 20.50
20
0940260208
ref: 20
CLAMP
€ 4.50
21-1
1317024F00
ref: 21-1
13170-24F02
CLAMP COMP,INTAKE PIPE
€ 29.00
21-2
1317024F01
ref: 21-2
13170-24F02
CLAMP,INTAKE P
€ 29.00
22
0712010453
ref: 22
07120-1045B
BOLT
€ 3.50
23
0712010553
ref: 23
07120-1055B
BOLT
€ 3.50
24
1116133E00
ref: 24
BOLT,CYL HEAD SIDE FACE
€ 8.00
25
1119113E00
ref: 25
WASHER,HEAD COVER
€ 4.00
26-1
1365051G10
ref: 26-1
SENSOR,WATER TEMP
€ 101.50
26-2
1365010G00
ref: 26-2
SENSOR,WATER TEMP
€ 64.50
27
0916812017
ref: 27
GASKET(12X17X1) (NAS)
€ 2.00
