FRONT WHEEL
GSX1300RZ HAYABUSA 2003 (K3) USA (E03)
Front wheel diagram GSX1300RZ HAYABUSA 2003 (K3) USA (E03)
FRONT WHEEL GSX1300RZ HAYABUSA 2003 (K3) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
5411133E1035W
ref: 1-1
54111-33E11-35W
WHEEL,FRONT (17XMT3.50)
€ 520.00
1-2
5411133E10019
ref: 1-2
54111-33E11-019
WHEEL FRONT,17
€ 613.50
1-2
5411133E10019
ref: 1-2
54111-33E11-019
WHEEL FRONT,17
€ 613.50
2
5473133E10
ref: 2
SPACER,FR HUB BEARING
€ 30.00
3
0926225061
ref: 3
BEARING(25X52X15)
€ 27.50
4
0928532004
ref: 4
SEAL,OIL(32X52X7)
€ 8.00
5-1
5471133E00
ref: 5-1
AXLE,FR
€ 151.00
5-2
5471142F00
ref: 5-2
AXLE,FR
€ 150.00
6
5471233E00
ref: 6
NUT,FR AXLE
€ 66.50
7-1
5921033E50
ref: 7-1
DISC,FR BRAKE
€ 247.00
7-1
5921033E50
ref: 7-1
DISC,FR BRAKE
€ 247.00
7-2
5921033EA0
ref: 7-2
59210-33EA1
DISC,FRONT BRA
€ 384.00
8-1
0910608125
ref: 8-1
09106-08148
BOLT 8X33
€ 6.00
8-2
0910608148
ref: 8-2
BOLT(8X33)
€ 6.00
9
5511024F00
ref: 9
TIRE,FR(120/70 ZR17 58W)
€ 763.00
9
5511024F00
ref: 9
TIRE,FR(120/70 ZR17 58W)
€ 763.00
10
4313024A00
ref: 10
VALVE ASSY,WHEEL RIM(TR412)
€ 7.00
11-1
5541100A00
ref: 11-1
BALANCER,WHEEL (10G)
€ 6.50
11-2
5541200A01
ref: 11-2
55412-17G00
BALANCER,WHEEL (20G)
€ 7.00
