Buy Suzuki GSX Parts Online


SEAT TAIL COVER (GSX500EE)

GSX500ES 1984 (E) GENERAL EXPORT (E01)

Seat tail cover (gsx500ee) diagram GSX500ES 1984 (E) GENERAL EXPORT (E01)

SEAT TAIL COVER (GSX500EE) GSX500ES 1984 (E) GENERAL EXPORT (E01)
SEAT TAIL COVER (GSX500EE) GSX500ES 1984 (E) GENERAL EXPORT (E01)
SEAT TAIL COVER (GSX500EE) GSX500ES 1984 (E) GENERAL EXPORT (E01)
prices are in EUR
ref
part #
description
quantity
1
455104345013Z
ref: 1
TAIL COVER, SEAT (BLACK)
€ 0.00
2
681604342071P
ref: 2
TAPE SET, SEAT TAIL COVER
€ 0.00
3
681664341071P
ref: 3
EMBLEM, "S" MARK
€ 4.00
4
6816631300764
ref: 4
EMBLEM (GOLD)
€ 3.50
5
682353130091R
ref: 5
EMBLEM
€ 12.00
6
455104345007P
ref: 6
TAIL COVER, SEAT (RED)
€ 0.00
7
681604342060D
ref: 7
TAPE SET, SEAT TAIL COVER
€ 0.00
8
681664341060D
ref: 8
EMBLEM,SEAT TAIL (S)
681664341060D
€ 4.50
9
6816631300064
ref: 9
EMBLEM(WHITE)
6816631300064
€ 3.50
10
682353130091R
ref: 10
EMBLEM
€ 12.00
11
4556243401
ref: 11
BLIND,SEAT TAIL COVER
€ 5.50
12
0211206168
ref: 12
SCREW
0211206168
€ 2.50
13
0832121068
ref: 13
LOCK WASHER
0832121068
€ 2.50
14
0916906010
ref: 14
WASHER
0916906010
€ 3.00
15
9499043400
ref: 15
BOX,SEAT TAIL
€ 30.50
16
0831931068
ref: 16
NUT
0831931068
€ 2.50
17
0980000269
ref: 17
TOOL ASSY
€ 53.00
