Buy Suzuki GSX Parts Online


SEAT TAIL COVER (GSX500ESF)

GSX500ES 1984 (E) GENERAL EXPORT (E01)

Seat tail cover (gsx500esf) diagram GSX500ES 1984 (E) GENERAL EXPORT (E01)

SEAT TAIL COVER (GSX500ESF) GSX500ES 1984 (E) GENERAL EXPORT (E01)
SEAT TAIL COVER (GSX500ESF) GSX500ES 1984 (E) GENERAL EXPORT (E01)
SEAT TAIL COVER (GSX500ESF) GSX500ES 1984 (E) GENERAL EXPORT (E01)
prices are in EUR
ref
part #
description
quantity
1-1
45590434707JH
ref: 1-1
E15
COVER, SEAT TAIL
€ 0.00
1-2
45590434807JH
ref: 1-2
E39
COVER, SEAT TAIL
€ 0.00
1-3
45590434707JJ
ref: 1-3
E15
COVER, SEAT TAIL
€ 0.00
1-4
45590434807JJ
ref: 1-4
E39
COVER, SEAT TAIL
€ 0.00
2
6816043460019
ref: 2
TAPE SET,SEAT TAIL COVER
€ 0.00
3
6816631300064
ref: 3
EMBLEM(WHITE)
6816631300064
€ 3.50
4
682350470091R
ref: 4
EMBLEM
€ 2.50
5
4556243401
ref: 5
BLIND,SEAT TAIL COVER
€ 5.50
6
0211206168
ref: 6
SCREW
0211206168
€ 2.50
7
0832121068
ref: 7
LOCK WASHER
0832121068
€ 2.50
8
0916906C10
ref: 8
WASHER
€ 0.00
9
9499043400
ref: 9
BOX,SEAT TAIL
€ 30.50
10
0831931068
ref: 10
NUT
0831931068
€ 2.50
11
0980000269
ref: 11
TOOL ASSY
€ 53.00
