CYLINDER HEAD

ref

part #

description

quantity

1

1110018G00
ref: 1

HEAD ASSY,CYLINDER

€ 1,835.00

2

0712006403
ref: 2
07120-0640B

BOLT

€ 3.50

3

0920608007
ref: 3

PIN(6.2X8X16)

€ 2.50

4

1111511D70
ref: 4

GUIDE,VALVE

€ 18.50

5

1114135F00
ref: 5

GASKET,CYLINDER HEAD (NAS)

€ 63.50

6

0421111169
ref: 6

PIN

€ 2.00

7

0910310330
ref: 7

BOLT(10X105)

€ 7.00

8

0916010082
ref: 8

WASHER(10.5X19X2)

€ 2.00

9

0910306222
ref: 9

BOLT(6X12)

€ 2.00

10

0712006503
ref: 10
07120-0650B

BOLT,CYL.OIL P

€ 2.50

11

0916806023
ref: 11

GASKET(5.8X13X1.2) (NAS)

€ 2.00

12-1

0948200458
ref: 12-1

PLUG,SPARK(NGK CR9E)

€ 8.50

12-2

0948200459
ref: 12-2

PLUG,SPARK(U27ESR-N)

€ 8.50

12-3

0948200456
ref: 12-3

PLUG,SPARK(CR8E)

€ 7.00

12-4

0948200460
ref: 12-4

PLUG,SPARK(CR10E)

€ 8.50

12-5

0948200457
ref: 12-5

PLUG,SPARK(U24ESR-N)

€ 7.00

12-6

0948200461
ref: 12-6

PLUG,SPARK(U31ESR-N)

€ 8.50

13

1310140F10
ref: 13

PIPE ASSY,INTAKE

€ 41.00

14

0928046006
ref: 14

O RING(D:2.4,ID:47X42)

€ 8.00

15

1317035F01
ref: 15

CLAMP,INTAKE PIPE

€ 27.00

16

0212206163
ref: 16
02122-0616A

SCREW ,6X16

€ 2.00

17

0910610069
ref: 17

BOLT(10X45)

€ 4.50

18

0910610070
ref: 18

BOLT(10X55)

€ 4.50

19

0928004004
ref: 19

O RING(D:1.2,ID:4)

€ 2.00

20

0949380005
ref: 20

JET(8)

€ 12.00

21

1365010G00
ref: 21

SENSOR,WATER TEMP

€ 64.50

22

0916812017
ref: 22

GASKET(12X17X1) (NAS)

€ 2.00
