RADIATOR

GSXR1000 2004 (K4) USA (E03)

Radiator diagram GSXR1000 2004 (K4) USA (E03)

RADIATOR GSXR1000 2004 (K4) USA (E03)

RADIATOR GSXR1000 2004 (K4) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1771040F20
ref: 1

RADIATOR ASSY,WATER

€ 814.00

2

1773012C20
ref: 2
17730-08J00

CAP COMP,RADIATOR

€ 40.00

3

0911806097
ref: 3

BOLT(6X25)

€ 2.50

4-1

0918006290
ref: 4-1

SPACER(6.5X10X12)

€ 2.50

4-2

0918006290
ref: 4-2

SPACER(6.5X10X12)

€ 2.50

5

0918006293
ref: 5

SPACER(6.5X10X14)

€ 2.00

6

0932010042
ref: 6

CUSHION

€ 4.00

7-1

0932010051
ref: 7-1

CUSHION

€ 3.50

7-2

0932010051
ref: 7-2

CUSHION

€ 3.50

8

1775035F01
ref: 8

BRACKET,RADIATOR

€ 11.00

9

0155006123
ref: 9
01550-0612A

BOLT

€ 2.50

10

1780040F20
ref: 10

FAN ASSY,RADIATOR

€ 520.50

11

1771140F00
ref: 11

BOLT,FAN ASSY

€ 3.50

12

1771240F00
ref: 12

NUT,FAN ASSY

€ 3.50
