REAR FENDER UPPER
GSXR600 2009 (K9) USA (E03)
Rear fender upper diagram GSXR600 2009 (K9) USA (E03)
REAR FENDER UPPER GSXR600 2009 (K9) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
6311137H00
ref: 1
FENDER,RR FR
€ 99.00
2-1
6311237H00019
ref: 2-1
COVER,RR FENDER FR
€ 117.50
2-2
6311237H00YKV
ref: 2-2
COVER,RR FENDER FR
€ 73.50
2-3
6311237H00YPA
ref: 2-3
COVER,RR FENDER FR
€ 73.50
2-4
6311237H00YME
ref: 2-4
COVER,RR FENDER FR
€ 73.50
2-5
6311237H00YSF
ref: 2-5
COVER,RR FENDER FR
€ 73.50
3
0918006268
ref: 3
SPACER(6.5X9X13.5)
€ 2.00
4
0932009016
ref: 4
CUSHION
€ 2.50
5
6316143E10
ref: 5
BOLT
€ 2.50
6
4741437H00
ref: 6
BRACKET,ELECTRIC PARTS HOLDER
€ 10.00
7
035410516A
ref: 7
SCREW
€ 1.50
8
0946200034
ref: 8
BAND
€ 4.50
9
0980021039
ref: 9
TOOL ASSY
€ 73.00
10
6311537H00
ref: 10
CUSHION,RR COVER NO.2
€ 2.00
11
3365229100
ref: 11
33651-37000
PROTECTOR,20X9
€ 5.00
12
6311637H00
ref: 12
CUSHION,RR FENDER
€ 2.50
