Buy Suzuki GV Parts Online


CLUTCH MASTER CYLINDER

GV1400GC CAVALCADE 1987 (H) USA (E03)

Clutch master cylinder diagram GV1400GC CAVALCADE 1987 (H) USA (E03)

CLUTCH MASTER CYLINDER GV1400GC CAVALCADE 1987 (H) USA (E03)
CLUTCH MASTER CYLINDER GV1400GC CAVALCADE 1987 (H) USA (E03)
CLUTCH MASTER CYLINDER GV1400GC CAVALCADE 1987 (H) USA (E03)
prices are in EUR
ref
part #
description
quantity

5980024A01
ref:
59800-24A02
CYLINDER ASSEMBLY,CLUTCH MASTER
€ 237.00
1
5980008810
ref: 1
PISTON & CUP SET
5980008810
€ 36.50
2
5966644300
ref: 2
BOOT
5966644300
€ 6.00
3
5987108A00
ref: 3
ROD,PUSH
5987108A00
€ 5.50
4
5989208A00
ref: 4
BUSH
5989208A00
€ 5.50
5
5966749460
ref: 5
5966749460
6
5966924A00
ref: 6
CAP
5966924A00
€ 30.50
7
6968949300
ref: 7
SCREW
6968949300
€ 1.50
8
5967124A00
ref: 8
HOLDER,MASTER CYLINDER
€ 16.00
9
0711006205
ref: 9
07130-0620B
BOLT
€ 3.00
10
0925005009
ref: 10
CAP(OD:10)
0925005009
€ 2.50
