REAR FENDER
RG125BU 1988 (J) (E02 E04)
Rear fender diagram RG125BU 1988 (J) (E02 E04)
REAR FENDER RG125BU 1988 (J) (E02 E04)
×
prices are in EUR
ref
part #
description
quantity
1-1
6311036A01
ref: 1-1
FENDER, REAR
€ 111.00
1-2
6311036A11
ref: 1-2
E15, E17, E18
FENDER, REAR
€ 118.50
2
0110706257
ref: 2
BOLT
€ 2.00
3
0916006006
ref: 3
WASHER
€ 2.00
4
0916006056
ref: 4
WASHER(6.5X18X1)
€ 2.00
5
0110706206
ref: 5
BOLT,M6X1X20
€ 2.00
6
0916006057
ref: 6
WASHER
€ 2.00
7
0918006011
ref: 7
SPACER (6.1X9X9)
€ 2.00
8
0932009016
ref: 8
CUSHION
€ 2.50
9
0831921068
ref: 9
NUT 6MM
€ 2.00
10
6331136A00
ref: 10
E15, E17, E18
EXTENSION, REAR FENDER
€ 0.00
11
0214205164
ref: 11
E15, E17, E18
SCREW
€ 2.50
12
0831931056
ref: 12
E15, E17, E18
NUT
€ 3.00
