REAR SWINGING ARM
RM85 2010 (L0) USA (E03)
Rear swinging arm diagram RM85 2010 (L0) USA (E03)
REAR SWINGING ARM RM85 2010 (L0) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
6100003BB0
ref: 1-1
SWINGINGARM ASSY,RR
€ 899.00
1-2
6100003BC0
ref: 1-2
SWINGINGARM ASSY,RR
€ 711.50
2
6126102B00
ref: 2
BUSHING,SWGARM PIVOT
€ 9.50
3
0926317039
ref: 3
BEARING(17X24X20)
€ 18.00
4
6112803B70
ref: 4
PLATE,SWGARM RR
€ 14.50
5
021220410B
ref: 5
SCREW
€ 2.50
6
6121102B40
ref: 6
SHAFT,RR SWINGINGARM PIVOT
€ 10.00
7
6125102B40
ref: 7
SPACER,RR SWGARM PIVOT
€ 14.00
8
0821112282
ref: 8
WASHER
€ 2.00
9
6126203B00
ref: 9
COVER,SWGARM PIVOT
€ 5.00
10
083220112B
ref: 10
WASHER
€ 2.00
11
083192112A
ref: 11
NUT
€ 4.00
12
6127302B20
ref: 12
BUFFER,CHAIN TOUCH DEFENSE
€ 24.50
13
0910306234
ref: 13
BOLT(6X16)
€ 2.50
14
0916906057
ref: 14
WASHER
€ 4.00
15
6134202B40
ref: 15
PLATE,GUIDE CHAIN OUTER
€ 15.00
16
6134302B40
ref: 16
GUIDE,CHAIN
€ 19.00
17
6134802B20
ref: 17
DEFENSE,CHAIN GUIDE
€ 11.00
18
0910306251
ref: 18
BOLT(6X30)
€ 2.50
19
0910306241
ref: 19
BOLT(6X40)
€ 2.50
20
0910306234
ref: 20
BOLT(6X16)
€ 2.50
21
6144503B00
ref: 21
WASHER,CHAIN ADJUSTER
€ 18.50
22
0915908034
ref: 22
NUT
€ 2.00
23
0910008301
ref: 23
BOLT(8X43)
€ 2.50
