STAND

RM85 2010 (L0) USA (E03)

Stand diagram RM85 2010 (L0) USA (E03)

STAND RM85 2010 (L0) USA (E03)

STAND RM85 2010 (L0) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

4231003B10
ref: 1-1

STAND

€ 59.50

1-2

4231003B20
ref: 1-2

STAND

€ 96.50

2

4355114D21
ref: 2

FOOTREST,R

€ 186.50

3

4356114D21
ref: 3

FOOTREST,L

€ 186.50

4

0944816032
ref: 4

SPRING

€ 2.00

5

0920010013
ref: 5

PIN

€ 2.50

6

0920401002
ref: 6

PIN

€ 1.50
