REAR WHEEL
SV1000 2005 (K5) USA (E03)
Rear wheel diagram SV1000 2005 (K5) USA (E03)
REAR WHEEL SV1000 2005 (K5) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
6411135F11Y6G
ref: 1-1
WHEEL,RR(17M/CXMT5.50)
€ 596.50
1-1
6411135F11Y6G
ref: 1-1
WHEEL,RR(17M/CXMT5.50)
€ 596.50
1-2
6411135F11019
ref: 1-2
WHEEL,RR(17M/CXMT5.50)
€ 782.00
1-2
6411135F11019
ref: 1-2
WHEEL,RR(17M/CXMT5.50)
€ 782.00
2
6473135F00
ref: 2
64731-35F10
SPACER,REAR HUB BEARING
€ 40.00
3
0926228043
ref: 3
BEARING(28X52X12)
€ 22.50
4
0928437001
ref: 4
SEAL,OIL(37X52X8)
€ 9.00
5
6921140F10
ref: 5
DISC,RR BRAKE
€ 199.50
6
0910608148
ref: 6
BOLT(8X33)
€ 6.00
7
6471133E10
ref: 7
AXLE,RR
€ 129.00
8
0914125001
ref: 8
NUT
€ 25.00
9
0411140408
ref: 9
04111-4040A
PIN, COTTER
€ 2.00
10
6474135F00
ref: 10
SPACER,RR AXLE,R
€ 9.00
11
6475135F00
ref: 11
SPACER,RR AXLE,L
€ 25.50
12
6461035F10
ref: 12
DRUM, REAR SPROCKET
€ 219.00
13
6473335F00
ref: 13
RETAINER,RR SPROCKET DRUM
€ 21.50
14
0926232007
ref: 14
09262-32022
BEARING
€ 49.00
15
0928539001
ref: 15
SEAL,OIL(39X65X7)
€ 9.00
16
6465135F00
ref: 16
ABSORBER,RR HUB SHOCK
€ 10.00
17
6451140F30
ref: 17
SPROCKET,RR(40T-530)
€ 89.00
18
0831931107
ref: 18
NUT
€ 3.00
19-1
6511016G10
ref: 19-1
65110-32F00
TIRE COMP.RR.18
€ 199.00
19-1
6511016G10
ref: 19-1
65110-32F00
TIRE COMP.RR.18
€ 199.00
19-2
6511016G00
ref: 19-2
TIRE, RR 180/55 (PURCHASE LOCALLYSV1000K3)
€ 0.00
19-2
6511016G00
ref: 19-2
TIRE, RR 180/55 (PURCHASE LOCALLYSV1000K3)
€ 0.00
20
4313024A00
ref: 20
VALVE ASSY,WHEEL RIM(TR412)
€ 7.00
21-1
4322273H10
ref: 21-1
WEIGHT,WHEEL BALANCE 10G
€ 4.00
21-2
4322473H10
ref: 21-2
WEIGHT,WHEEL BALANCE 20G
€ 5.00
21-3
4322673H10
ref: 21-3
WEIGHT,WHEEL BALANCE 30G
€ 6.00
