THROTTLE BODY
SV1000S 2007 (K7) USA (E03)
Throttle body diagram SV1000S 2007 (K7) USA (E03)
THROTTLE BODY SV1000S 2007 (K7) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
1340516G30
ref: 1-1
13405-16G31
INJECTION ASSY
€ 911.00
1-2
1340516G40
ref: 1-2
INJECTION ASSY
€ 0.00
2
1360206128
ref: 2
SCREW
€ 2.50
3
1331106G00
ref: 3
RING
€ 6.50
4
1354842F00
ref: 4
SCREW
€ 3.50
5
1327144B00
ref: 5
SPRING
€ 4.00
6
1326896111
ref: 6
SPRING,THROTTLE SCREW
€ 4.50
7
1360539F00
ref: 7
SCREW
€ 4.00
8
1358016G00
ref: 8
SENSOR ASSY
€ 155.50
9
1368339F10
ref: 9
HOSE
€ 2.50
10
1327193011
ref: 10
SPRING
€ 4.50
11
1338609410
ref: 11
WASHER
€ 2.50
12
1327006G00
ref: 12
SCREW ASSY,ADJUST
€ 82.50
13
1355013D60
ref: 13
SENSOR ASSY,THROTTLE
€ 129.50
14
1360502F00
ref: 14
SCREW
€ 3.00
15
1362716G30
ref: 15
PLATE
€ 17.00
16
0211204107
ref: 16
SCREW
€ 2.00
17
1326889J00
ref: 17
SPRING
€ 6.00
18
1355217G00
ref: 18
ROD ASSY
€ 24.00
19
1355216G00
ref: 19
ROD ASSY
€ 24.50
20
1327916G10
ref: 20
PLATE,IDLE ADJUST
€ 4.50
21
0150006123
ref: 21
01500-0612A
BOLT
€ 2.00
