prices are in EUR
ref
part #
description
quantity
2
PANEL,REAR BRAKE ANCHOR
3
SHOE,BRAKE (MCA)
4
SPRING(L:34)
5-1
CAM,FRONT BRAKE
6
LEVER,RR BRAKE CAM
7
WASHER (14.5X22X1.6)
8
O-RING (D:2.4 ID:13.8)
9
WASHER
10
NUT
11
BOLT(6X33)
13
WASHER,RR AXLE
14
NUT 12MM
15
NO PRODUCT DESCRIPTION AVAILABLE
16
COTTER PIN
18
SPACER (12.6X19X79)
19
SPACER, REAR AXLE LH
20
BEARING
21
BEARING
22
BEARING
23-1
SPROCKET, REAR (NT:49)
23-2
NO PRODUCT DESCRIPTION AVAILABLE
0
NO PRODUCT DESCRIPTION AVAILABLE
23-3
NO PRODUCT DESCRIPTION AVAILABLE
23-4
NO PRODUCT DESCRIPTION AVAILABLE
0
NO PRODUCT DESCRIPTION AVAILABLE
25
LOCK WASHER
27
ADJUSTER, CHAIN
28
ADJUSTER,CHAIN
29
LOCK WASHER
30
NUT
31-2
NO PRODUCT DESCRIPTION AVAILABLE
31-3
NO PRODUCT DESCRIPTION AVAILABLE
0
NO PRODUCT DESCRIPTION AVAILABLE
32-2
NO PRODUCT DESCRIPTION AVAILABLE
33-1
PROTECTOR,INNER TUBE
33-2
NO PRODUCT DESCRIPTION AVAILABLE
33-3
NO PRODUCT DESCRIPTION AVAILABLE
0
NO PRODUCT DESCRIPTION AVAILABLE
34-2
NO PRODUCT DESCRIPTION AVAILABLE
35-1
SPOKE SET,REAR WHEEL
35-2
NO PRODUCT DESCRIPTION AVAILABLE
