prices are in EUR
ref
part #
description
quantity
1-1
SWING ARM ASSEMBLY,REAR
1-2
SWING ARM ASSEMBLY,REAR
2
BEARING(22X29X20)
3
SPACER,REAR SWING ARM PIVOT
4
SPACER,RR SWGARM PIVOT
5
CVR,RR SWGARM DUST SEAL(OD:40)
6
WASHER
7
SHAFT,RR SWINGINGARM PIVOT
8
NUT
9
CAP,REAR SWING ARM PIVOT
10-1
COVER,REAR SWING ARM PIVOT
10-2
COVER,REAR SWING ARM PIVOT
11
BOOT,PROPELLER SHAFT
12
CLAMP
13
SCREW 4X25
15
BOLT(10X24.5)
16
WASHER (10.5X18X1)
17
NUT
18
PIN 16X20
20
WASHER (10.5X18X1)
21
NUT
22
PIN 16X20
23
CAP
24
ABSORBER ASSEMBLY,REAR SHOCK
25
WASHER
26
NUT, LOWER LH
27
BOLT(10X36)
29
WASHER
30
NUT, LOWER LH
30
NUT, LOWER LH
30
NUT, LOWER LH
30
NUT, LOWER LH
