STARTING MOTOR (MODEL M)

VS700GLP INTRUDER 1988 (J) USA (E03)

Starting motor (model m) diagram VS700GLP INTRUDER 1988 (J) USA (E03)

prices are in EUR

ref

part #

description

quantity

3110045C00
ref: 1
31100-45C01

MOTOR ASSEMBLY,STARTING

€ 472.00

3131045C00
ref: 2

ARMATURE

€ 127.00

3136147010
ref: 3
31170-43400

SHIM,ARMATURE

€ 3.50

3114338300
ref: 4

O RING

€ 3.50

3113245C00
ref: 5

HOLDER SET,BRUSH

€ 46.00

3115038A00
ref: 6

BRACKET SET

€ 79.50

3117238300
ref: 7

BUSHING

€ 4.00

3117388C00
ref: 8

BUSHING

€ 6.00

0831032068
ref: 9
08310-00067

NUT

€ 2.50

3126444110
ref: 10

O RING

€ 8.00

3128138A00
ref: 11
31281-24B10

BOLT

€ 5.00

3115638A00
ref: 12

O RING

€ 8.00

0836135066
ref: 13
08361-3506A

NUT

€ 2.00

0154706607
ref: 14

BOLT

€ 2.50

STARTING MOTOR (MODEL M)

all assemblies
