CARBURETOR (FRONT)

VS800GL BOULEVARD S50 2005 (K5) CALIFORNIA (E33)

Carburetor (front) diagram VS800GL BOULEVARD S50 2005 (K5) CALIFORNIA (E33)

CARBURETOR (FRONT) VS800GL BOULEVARD S50 2005 (K5) CALIFORNIA (E33)
CARBURETOR (FRONT) VS800GL BOULEVARD S50 2005 (K5) CALIFORNIA (E33)
CARBURETOR (FRONT) VS800GL BOULEVARD S50 2005 (K5) CALIFORNIA (E33)
prices are in EUR
ref
part #
description
quantity
1-1
1321038E10
ref: 1-1
13210-38E11
CARBURETOR ASSEMBLY,FRONT
€ 363.00
1-2
1321038E11
ref: 1-2
CARBURETOR ASSY,FR
€ 363.00
1-3
1321038E50
ref: 1-3
13210-38E51
CARBURETOR ASSEMBLY,FRONT
€ 363.00
1-4
1321038E51
ref: 1-4
CARBURETOR ASSY, FRONT
€ 363.00
2
0211233073
ref: 2
SCREW
€ 0.00
3
1338747010
ref: 3
RING
1338747010
€ 7.50
4
1339410010
ref: 4
CLIP
1339410010
€ 4.50
5
1338244030
ref: 5
WASHER
1338244030
€ 3.50
6
1338844030
ref: 6
SPRING
1338844030
€ 6.00
7
1338345C20
ref: 7
NEEDLE,JET
1338345C20
€ 10.00
8
0949400892
ref: 8
JET,NEEDLE(P-2M)
€ 0.00
9
1360538B00
ref: 9
SCREW
1360538B00
€ 7.50
10
0211204103
ref: 10
02112-0410A
SCREW
0211204103
€ 1.00
11
1368938A00
ref: 11
SPRING
1368938A00
€ 8.50
12
0935250823600
ref: 12
44420-44AR0
HOSE(5X8.2X600)
0935250823600
€ 13.00
13
1368104010
ref: 13
CAP
1368104010
€ 3.00
14
1327847090
ref: 14
O RING
1327847090
€ 2.00
15
1341838A00
ref: 15
HOLDER,GUIDE
1341838A00
€ 11.50
16
1341101400
ref: 16
PLUNGER,STARTER
1341101400
€ 11.50
17
1341708210
ref: 17
SPRING
1341708210
€ 4.50
18
0949265005
ref: 18
JET,AIR(65)
0949265005
€ 7.50
19
0949240021
ref: 19
JET,PILOT(40)
0949240021
€ 17.50
20
1350238A00
ref: 20
COVER,DIAPHRAGM
1350238A00
€ 34.00
21
1350005A10
ref: 21
DIAPHRAGM,CARBURETOR
1350005A10
€ 178.00
22
1350338B00
ref: 22
SPRING,DIAPHRAGM
1350338B00
€ 12.00
23
1338937400
ref: 23
PLATE
1338937400
€ 5.50
24
0212204103
ref: 24
02122-0410A
SCREW,UPPER
€ 2.50
25
1325138A00
ref: 25
O RING,FLOAT CHAMBER
1325138A00
€ 6.50
26
1338505A11
ref: 26
HOLDER,MAIN JET
1338505A11
€ 14.00
27
0949125018
ref: 27
JET,MAIN(127.5)
0949125018
€ 15.50
28
1324713A00
ref: 28
13247-02340
SCREW,DRAIN
1324713A00
€ 5.50
29
0940406432
ref: 29
CLAMP(L:65)
0940406432
€ 2.50
30
1348005A10
ref: 30
DIAPHRAGM ASSY
1348005A10
€ 54.50
31
1348145C10
ref: 31
SPRING
1348145C10
€ 5.50
32
1348438A00
ref: 32
COVER
1348438A00
€ 20.50
33
1360104148
ref: 33
SCREW
1360104148
€ 2.50
34
0831000047
ref: 34
NUT
0831000047
€ 2.00
35
0211204303
ref: 35
02112-0430B
SCREW
0211204303
€ 2.00
36
1355438A00
ref: 36
LEVER,ASSY
€ 15.00
37
1337619F00
ref: 37
FILTER
1337619F00
€ 6.50
38
1337435C00
ref: 38
O RING,NEEDLE VALVE SEAT
1337435C00
€ 6.00
39
1337039A00
ref: 39
VALVE ASSY,NEEDLE
1337039A00
€ 67.50
40
1360205A10
ref: 40
SCREW
1360205A10
€ 4.00
41
1325038B00
ref: 41
FLOAT
1325038B00
€ 32.00
42
1325420010
ref: 42
PIN,FLOAT
1325420010
€ 3.00
43
0211205127
ref: 43
SCREW
0211205127
€ 2.50
44
1352346110
ref: 44
GASKET,DRAIN PLUG (NAS)
1352346110
€ 3.00
45
0211205063
ref: 45
02112-0506B
SCREW
€ 2.00
46
1341538300
ref: 46
E RING
1341538300
€ 2.00
47
1367138A00
ref: 47
CLIP
1367138A00
€ 10.50
48
0935260103600
ref: 48
HOSE(6X10X600)
0935260103600
€ 18.00
49-1
1327947070
ref: 49-1
SCREW,PILOT
1327947070
€ 11.50
49-2
1327947070
ref: 49-2
SCREW,PILOT
1327947070
€ 11.50
50
1326847070
ref: 50
SPRING
1326847070
€ 5.00
51
1329529900
ref: 51
O RING,PILOT AIR SCREW
1329529900
€ 4.00
52
1329129900
ref: 52
WASHER
1329129900
€ 2.00
53
1328105A00
ref: 53
PLUG
1328105A00
€ 3.50
54
1368338B00
ref: 54
13683-38B01
(CA) HOSE SET,FUEL
€ 19.50
55
1368338A20
ref: 55
13683-38A21
HOSE ASSEMBLY
1368338A20
€ 70.00
56-1
1364138A00
ref: 56-1
13641-38A01
CABLE,IDLE SYNCRO
1364138A00
€ 16.50
56-2
1364138A01
ref: 56-2
CABLE,IDLE SYNCRO
1364138A01
€ 16.50
