FUEL EVAPORATIVE SYSTEM

VZ1600 BOULEVARD M95 2005 (K5) CALIFORNIA (E33)

Fuel evaporative system diagram VZ1600 BOULEVARD M95 2005 (K5) CALIFORNIA (E33)

prices are in EUR

ref

part #

description

quantity

11012

K110121388
ref: 11012

CAP,CANISTER

€ 0.00

14073

K140731219
ref: 14073

DUCT,CANISTER

€ 0.00

16164

K161641070
ref: 16164

CANISTER

€ 0.00

16165

K161651001
ref: 16165

SEPARATOR

€ 0.00

92005

K920051206
ref: 92005

FITTING

€ 0.00

92037

K920371104
ref: 92037

CLAMP,HOSE

€ 0.00

92037A

KK92037147
ref: 92037A

CLAMP,TUBE

€ 8.00

92037B

K920371512
ref: 92037B

CLAMP,CANISTER

€ 0.00

92037C

K920371712
ref: 92037C

CLAMP

€ 3.00

92072

KK92072045
ref: 92072

BAND,L=90

€ 0.00

92072A

K920721419
ref: 92072A

BAND,L=50

€ 0.00

92191

K921911375
ref: 92191

TUBE,THROTTLE-SEPARATOR,WHITE

€ 0.00

92191A

K921911414
ref: 92191A

TUBE,4X9X180,WHITE

€ 0.00

92191B

K921911677
ref: 92191B

TUBE,SEPARATOR-CANISTER,BLUE

€ 0.00

92191C

K921911678
ref: 92191C

TUBE,CANISTER-CLEANER,GREEN

€ 0.00

92191D

K921911695
ref: 92191D

TUBE,TANK-SEPARATOR,RED

€ 0.00

92191E

K921911696
ref: 92191E

TUBE,TANK-SEPARATOR,BLUE

€ 0.00
