FOOTREST

DR125S 1987 (H) (E01 E02 E04 E15 E18 E21 E24)

Footrest diagram DR125S 1987 (H) (E01 E02 E04 E15 E18 E21 E24)

FOOTREST DR125S 1987 (H) (E01 E02 E04 E15 E18 E21 E24)
FOOTREST DR125S 1987 (H) (E01 E02 E04 E15 E18 E21 E24)
FOOTREST DR125S 1987 (H) (E01 E02 E04 E15 E18 E21 E24)
prices are in EUR
ref
part #
description
quantity
1-1
4351044A01019
ref: 1-1
MODEL F FOR 19F,14C
BAR,FRONT FOOTREST
€ 26.00
1-2
4351044A0119F
ref: 1-2
MODEL F FOR 10V,21C,
BAR,FRONT FOOTREST
€ 26.00
1-3
4351044A0213L
ref: 1-3
MODEL H
BAR,FRONT FOOTREST
€ 26.00
1-4
4351044A03019
ref: 1-4
MODEL J FOR 34S
BAR,FR FOOTREST,R
4351044A03019
€ 26.00
1-5
4351044A0334S
ref: 1-5
MODEL J FOR 14L,21C
BAR,FRONT FOOTREST,RIGHT
€ 0.00
2-1
4352044A01019
ref: 2-1
MODEL F FOR 19F,14C
BAR,FRONT FOOTREST,LEFT
€ 24.00
2-2
4352044A0119F
ref: 2-2
MODEL F FOR 10V,21C,
BAR,FRONT FOOTREST,LEFT
€ 24.00
2-3
4352044A0213L
ref: 2-3
MODEL H
BAR,FRONT FOOTREST,LEFT
€ 24.00
2-4
4352044A03019
ref: 2-4
MODEL J FOR 34S
BAR,FR FOOTREST,L
€ 24.00
2-5
4352044A0334S
ref: 2-5
MODEL J FOR 14L,21C
BAR,FR FOOTREST,L
4352044A0334S
€ 15.00
3-1
4353044A01019
ref: 3-1
MODEL F FOR 19F,14C
BRACKET,FRONT FOOTREST
€ 24.50
3-2
4353044A0119F
ref: 3-2
MODEL F FOR 10V,21C,
BRACKET,FRONT FOOTREST
€ 24.50
3-3
4353044A0113L
ref: 3-3
MODEL H
BRACKET,FRONT FOOTREST
€ 24.50
3-4
4353044A01019
ref: 3-4
MODEL J FOR 34S
BRACKET,FRONT FOOTREST
€ 24.50
3-5
4353044A0134S
ref: 3-5
MODEL J FOR 14L,21C
BRACKET,FRONT FOOTREST
€ 24.50
4-1
4354044A01019
ref: 4-1
MODEL F FOR 19F,14C
HOLDER COMP,FRONT FOOT
€ 24.50
4-2
4354044A0119F
ref: 4-2
MODEL F FOR 10V,21C,
HOLDER COMP,FRONT FOOT
€ 24.50
4-3
4354044A0113L
ref: 4-3
MODEL H
HOLDER COMP,FRONT FOOT
€ 24.50
4-4
4354044A01019
ref: 4-4
MODEL J FOR 34S
HOLDER COMP,FRONT FOOT
€ 24.50
4-5
4354044A0134S
ref: 4-5
MODEL J FOR 14L,21C
HOLDER COMP,FRONT FOOT
€ 24.50
5-1
4355044A01019
ref: 5-1
MODEL F FOR 19F,14C
FOOTREST,FR
4355044A01019
€ 17.50
5-2
4355044A0119F
ref: 5-2
MODEL F FOR 10V,21C,
FOOTREST,FRONT
€ 17.50
5-3
4355044A0113L
ref: 5-3
MODEL H
FOOTREST,FRONT
€ 17.50
5-4
4355044A01019
ref: 5-4
MODEL J FOR 34S
FOOTREST,FR
4355044A01019
€ 17.50
5-5
4355044A0134S
ref: 5-5
MODEL J FOR 14L,21C
FOOTREST,FR
€ 0.00
6-1
0151712255
ref: 6-1
MODEL F/J
BOLT
€ 3.00
6-2
0152712258
ref: 6-2
MODEL H
BOLT
€ 2.50
7
0916010087
ref: 7
WASHER
€ 2.00
8
0832121104
ref: 8
WASHER,LOCK
0832121104
€ 3.00
9-1
0915910036
ref: 9-1
MODEL F/J
NUT
€ 3.00
9-2
0915910027
ref: 9-2
MODEL H
NUT
0915910027
€ 3.00
10
0920008002
ref: 10
PIN
0920008002
€ 2.00
11
0411120158
ref: 11
PIN
0411120158
€ 1.50
12
0931910053
ref: 12
BUSH
€ 17.50
13
0944814037
ref: 13
SPRING
0944814037
€ 2.50
14
4361003001
ref: 14
BAR,FOOTREST RUBBER
4361003001
€ 5.50
15
4361233200
ref: 15
RUBBER,PILLION FOOTREST
4361233200
€ 4.50
16
0916019006
ref: 16
WASHER (19.5X32X2)
0916019006
€ 2.00
17
0920006010
ref: 17
PIN
0920006010
€ 2.50
18
0411120208
ref: 18
PIN 20X20
0411120208
€ 1.50
