REAR FENDER

GN125E 1997 (V) USA (E03)

Rear fender diagram GN125E 1997 (V) USA (E03)

prices are in EUR

ref

part #

description

quantity

6311205302
ref: 1

BODY,FR

€ 44.00

6311038302
ref: 2
63110-38303

FENDER,REAR FENDER,REAR

€ 136.50

0158006163
ref: 3
01580-0616A

BOLT

€ 2.50

0932006504
ref: 4

CUSHION

€ 4.00

6831933E00
ref: 5
68319-33E01

LABEL (WARNING SAFETY),E

€ 8.00

6833205320
ref: 6

LABEL (TIRE AIR PRESSURE)

€ 0.00

6835326E01
ref: 7
68353-26E02

LABEL (MANUAL NOTICE)

€ 3.50

6838738300
ref: 8

LABEL (PIPING DIAGRAM)

€ 0.00

0158008257
ref: 9

BOLT

€ 3.00

0831610083
ref: 10
08316-1008B

NUT

€ 3.00

MANUAL, OWNER'S (MODEL TDRAWING NOT SHOWN)

€ 0.00
