COWLING

GS1000S 1979 (N) USA (E03)

Cowling diagram GS1000S 1979 (N) USA (E03)

COWLING GS1000S 1979 (N) USA (E03)

COWLING GS1000S 1979 (N) USA (E03)

prices are in EUR

ref

part #

description

quantity

3

9459149000A
ref: 3

MOLDING,COWLING

€ 4.50

6

9451049001
ref: 6

BRACKET,COWLING,UPPER

€ 29.00

7

9452049001
ref: 7

BRACKET,COWLING,UPPER

€ 47.00

8

9457349000
ref: 8

CUSHION,COWLING

€ 5.50

9

021420512A
ref: 9

SCREW

€ 1.50

10

0831000057
ref: 10

NUT

€ 2.50

11

0832101057
ref: 11

WASHER,LOCK

€ 2.00

12

0832201057
ref: 12

WASHER

€ 2.50

13

0932005008
ref: 13

CUSHION

€ 5.00

14

0150006167
ref: 14

BOLT

€ 3.00

15

0832201067
ref: 15

WASHER

€ 2.00

16

0832101067
ref: 16

WASHER,LOCK

€ 2.50

17

9465148B00
ref: 17

COVER,MOLDING END

€ 7.50
