CRANKCASE

ref

part #

description

quantity

1

1130044890
ref: 1

CRANKCASE SET

€ 476.50

2

0920613004
ref: 2

PIN(10.4X13X22)

€ 3.00

3

0920611005
ref: 3
09206-11017

PIN (11X20)(SUS)

€ 6.50

4

0711008706
ref: 4
07130-0870B

BOLT (8X70)

€ 4.00

5

0910308094
ref: 5
09103-08182

BOLT

€ 4.50

6

0910308024
ref: 6
09103-08134

BOLT

€ 3.00

7

0151708705
ref: 7

BOLT (8X70)

€ 2.50

8

0151708655
ref: 8
01550-0865A

BOLT (8X65)

€ 3.00

9

0151708455
ref: 9
01550-0845A

BOLT

€ 3.00

10

0910306036
ref: 10
09103-06033

BOLT

€ 3.50

11

0910306067
ref: 11

BOLT(6X105)

€ 3.50

12

0151706905
ref: 12
01550-0690B

BOLT (6X90)

€ 3.50

13

0151706705
ref: 13
01550-0670B

BOLT

€ 2.50

14

0151706655
ref: 14

BOLT

€ 2.50

15

0151706505
ref: 15
01550-0650A

BOLT 6X50

€ 2.00

16

0151706455
ref: 16
01550-0645A

BOLT (6X45)

€ 2.50

17

0831616085
ref: 17
08316-1008B

NUT 8MM

€ 3.00

18

1643044501
ref: 18

VALVE ASSEMBLY,PISTON OIL

€ 6.50

19

0928004003
ref: 19

O-RING

€ 1.50

20

0949324005
ref: 20

JET,AIR

€ 13.00

21

0949324009
ref: 21

JET(12)

€ 10.50

22

0928004004
ref: 22

O RING(D:1.2,ID:4)

€ 2.00

23

0910010170
ref: 23

BOLT

€ 8.00

24

0910010145
ref: 24
09100-10033

BOLT

€ 46.50

25

0910010136
ref: 25
41189-17X00

BOLT

€ 28.50

26

0910010135
ref: 26
09100-10274

BOLT

€ 6.50

27

0831931105
ref: 27
08319-3110A

NUT 10MM

€ 3.00

28

0832211105
ref: 28
08322-0110A

WASHER

€ 2.50

29

0924714001
ref: 29
09247-14002

PLUG

€ 5.00

30

0916814004
ref: 30

GASKET(14X19.2X2) (NAS)

€ 2.50

31

0924152004
ref: 31

PLUG

€ 9.50
