REAR BRAKE HOSE

GS750A 1983 (D) USA (E03)

Rear brake hose diagram GS750A 1983 (D) USA (E03)

REAR BRAKE HOSE GS750A 1983 (D) USA (E03)

REAR BRAKE HOSE GS750A 1983 (D) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

6948049302
ref: 1
69480-08C01

HOSE,REAR BRAKE

€ 94.00

2

6924347000
ref: 2

GUIDE,BRAKE HOSE

€ 5.50

3

5924436200
ref: 3

GROMMET,BRAKE HOSE GUIDE

€ 4.00

4

0936010007
ref: 4
09360-10017

BOLT,UNION

€ 6.50

5

0916110005
ref: 5
09161-10009

WASHER

€ 2.00
