STEERING STEM (MODEL D)
GS850G 1983 (D) USA (E03)
Steering stem (model d) diagram GS850G 1983 (D) USA (E03)
STEERING STEM (MODEL D) GS850G 1983 (D) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5131149400291
ref: 1
HEAD,STEERING STEM
€ 198.50
2
5141049400291
ref: 2
51410-49430-291
STEM,STEERING
€ 249.00
3
0926530005
ref: 3
09265-30009
BEARING
€ 49.50
4
0821130402
ref: 4
09181-30184
WASHER,THRUST
€ 4.00
5
5153049470
ref: 5
BRACKET,HEADLAMP,RIGHT
€ 0.00
6
5154049470
ref: 6
BRACKET,HEADLAMP,LEFT
€ 0.00
7
5155349000
ref: 7
51553-34300
CUSHION,HEADLAMP BRACKET
€ 4.50
8
5143149470
ref: 8
JOINT,AIR,RIGHT
€ 0.00
9
5111714210
ref: 9
09280-06005
O-RING
€ 2.50
10
5143649470
ref: 10
51356-34370
O RING
€ 5.00
11
5143249470
ref: 11
JOINT,AIR,LEFT
€ 0.00
12
5111714210
ref: 12
09280-06005
O-RING
€ 2.50
13
5143649470
ref: 13
51356-34370
O RING
€ 5.00
14
5143349470
ref: 14
51433-49471
HOSE
€ 0.00
15
5111714210
ref: 15
09280-06005
O-RING
€ 2.50
16
5129349470
ref: 16
VALVE,FRONT FORK AIR
€ 8.50
17
5129449000
ref: 17
CAP,VALVE
€ 22.50
18
5135649400
ref: 18
51356-43530
WASHER,STEERING STEM
€ 4.00
19
5135349400
ref: 19
51352-43530
NUT,STEM HEAD
€ 8.50
20
0110708508
ref: 20
01500-08507
BOLT 8X50
€ 3.00
21
0831311088
ref: 21
08313-10087
NUT
€ 2.50
22
0832121088
ref: 22
08321-01087
LOCK WASHER
€ 2.00
23
0832221088
ref: 23
08322-01087
WASHER
€ 2.00
24
0110710558
ref: 24
01500-1055A
BOLT 10X55
€ 3.50
25
0832221108
ref: 25
08322-01107
WASHER
€ 2.50
26
0832121088
ref: 26
08321-01087
LOCK WASHER
€ 2.00
27
0831311108
ref: 27
08313-10107
NUT, LOWER LH
€ 2.50
28
0110708358
ref: 28
01500-0835B
BOLT
€ 3.50
29
0832121088
ref: 29
08321-01087
LOCK WASHER
€ 2.00
30
5621129320291
ref: 30
HOLDER,HANDLE(BLACK)
€ 12.00
31
0110708358
ref: 31
01500-0835B
BOLT
€ 3.50
32
0832121088
ref: 32
08321-01087
LOCK WASHER
€ 2.00
33
5163134200
ref: 33
NUT,STEERING STEM
€ 23.00
34
0926525008
ref: 34
09265-25019
TAPER,ROLLER BEARING
€ 48.50
35
5164340502
ref: 35
DUST SEAL,STEERING UPR
€ 8.00
36
5187045700
ref: 36
COVER,FRONT FORK
€ 0.00
37
6821149420
ref: 37
EMBLEM,FRONT FORK COVER
€ 16.50
38
5617049400
ref: 38
PAD,HANDLEBAR
€ 36.00
39
6828145100
ref: 39
EMBLEM,HANDLE COVER PAD
€ 14.00
40
0914803002
ref: 40
NUT
€ 3.00
41
0211205108
ref: 41
02112-05107
SCREW
€ 2.00
42
0832121058
ref: 42
08321-0105A
LOCK WASHER
€ 2.00
43
0832221058
ref: 43
08322-01057
WASHER
€ 2.50
