AIR CLEANER
GSF1200S BANDIT 2005 (K5) USA (E03)
Air cleaner diagram GSF1200S BANDIT 2005 (K5) USA (E03)
AIR CLEANER GSF1200S BANDIT 2005 (K5) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1370032F00
ref: 1
CLEANER ASSY,AIR
€ 269.00
2
1374032F00
ref: 2
CAP,AIR CLEANER
€ 44.50
3
1389131E10
ref: 3
TUBE,INLET
€ 22.00
4
1374631F00
ref: 4
GASKET,AIR CLEANER CAP (NAS)
€ 5.50
5
1378031F00
ref: 5
FILTER,AIR
€ 25.50
6
1385031F00
ref: 6
TUBE,BREATHER
€ 19.50
7
0940114404
ref: 7
CLIP
€ 2.00
8
0940116401
ref: 8
CLIP
€ 3.00
9
1387021458
ref: 9
TUBE,DRAIN
€ 23.50
10
0940113417
ref: 10
CLIP
€ 2.50
11
1388132F00
ref: 11
TUBE,OUTLET
€ 21.50
12
0940264203
ref: 12
CLAMP
€ 6.00
13
0214205123
ref: 13
02142-0512A
SCREW 5X12
€ 1.50
14
0155006123
ref: 14
01550-0612A
BOLT
€ 2.50
