ref
part #
description
quantity
2
PIN(10.4X13X22)
4
BOLT(6X105)
5
BOLT(8X105)
6
BOLT(8X125)
7
BOLT(8X115)
8-2
BOLT 6X35
9-1
BOLT
14-2
BOLT 6X35
15-1
BOLT
15-2
BOLT
16-1
BOLT
16-2
BOLT
17-1
BOLT 6X50
22
BOLT(8X95)
25
NUT
26
O RING(D:2.5,ID:21)
27
O RING(D:1.2,ID:4)
28
JET,AIR
29
JET
30
JET,OIL GALLERY
31
GASKET(12.1X16.2X3.7) (NAS)
32
PLUG(12X9)
33
GASKET(8.5X17X2.3) (NAS)
34
GASKET(6.2X13X1.2) (NAS)
35
PLUG
36
O RING(D:2.4,ID:16.8)
37-1
PLUG
37-2
PLUG,14X12
38
GASKET(14X19.2X2) (NAS)
39
UNION,OIL STAND
40
BEARING,CRANK THRUST(GREEN)
40
BEARING,CRANK THRUST(GREEN)
41-1
BEARING,CRANK THRUST(PINK)
41-1
BEARING,CRANK THRUST(PINK)
41-2
BEARING,CRANK THRUST(BROWN)
41-3
BEARING,CRANK THRUST(RED)
41-4
BEARING,CRANK THRUST(YELLOW)
41-5
BEARING,CRANK THRUST(GREEN)
41-6
BEARING,CRANK THRUST(BLUE)
41-7
BEARING,CRANK THRUST(ORANGE)
41-8
BEARING,CRANK THRUST(BLACK)
42
BOLT(10X180)
44
BOLT 10X55
46
NUT
47
NUT
48
NUT 12MM
49
WASHER,LOCK,10
50
WASHER
51
BUSH,ENGINE MOUNTING
52-2
SPACER,ENGINE MOUNT(L27)
53-1
SWITCH ASSEMBLY
53-2
SWITCH ASSEMBLY,OIL PRESSURE
