FRONT FENDER

GSX1300R HAYABUSA 2009 (K9) USA (E03)

Front fender diagram GSX1300R HAYABUSA 2009 (K9) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

5310015H00YHF
ref: 1-1

FENDER ASSY,FR(GRAY)

€ 245.50

1-2

5310015H00YPA
ref: 1-2

FENDER ASSY,FR(WHITE)

€ 245.50

1-3

5310015H00YAY
ref: 1-3

FENDER ASSY,FR(BLACK)

€ 245.50

1-4

5310015H00YKZ
ref: 1-4

FENDER ASSY,FR(BLUE)

€ 245.50

1-5

5310015H00YAY
ref: 1-5

FENDER ASSY,FR(BLACK)

€ 245.50

1-6

5310015H00YBD
ref: 1-6

FENDER ASSY,FR(WHITE)

€ 245.50

1-7

5310015H00019
ref: 1-7

FENDER ASSY,FR(BLACK)

€ 245.50

1-8

5310015H00YHG
ref: 1-8

FENDER ASSY,FR(GRAY)

€ 245.50

5333115H00
ref: 2

MUDGUARD,FR FENDER

€ 15.00

9442405H00
ref: 3

CUSHION

€ 2.50

0913906129
ref: 4

SCREW(6X16)

€ 3.00

0916006129
ref: 5

WASHER(6.5X16X1)

€ 2.00

083193106A
ref: 6

NUT

€ 2.50

0913906131
ref: 7

SCREW(6X16)

€ 4.00

0932009016
ref: 8

CUSHION

€ 2.50

0913906146
ref: 9

SCREW(6X16)

€ 3.00

FRONT FENDER

all assemblies
